Запчасти Komatsu PC75UU-3 ГЛАВН. КЛАПАН ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

702-21-09173

VALVE ASS'Y

1

702-21-55100

VALVE ASS'Y,RELIEF

2

702-16-53920

O-RING

3

07002-11623

O-RING

4

BLOCK

5

702-21-55310

VALVE

6

702-21-55460

SPRING

7

702-21-55420

O-RING

8

702-21-55520

O-RING

9

702-21-55440

O-RING

10

702-21-53120

FILTER

11

07000-11009

O-RING

12

702-21-55330

SPRING

13

702-21-55380

PLATE

14

702-21-55410

PLATE

15

01252-60820

BOLT

16

01643-50823

WASHER

17

702-21-55530

O-RING

18

BLOCK

19

702-21-55511

SPOOL

20

702-21-55640

SPRING

21

702-21-55620

PLUG

22

07002-11423

O-RING

23

702-21-55710

SEAT

24

702-21-55720

SPRING

25

04260-00793

BALL

26

07000-11009

O-RING

27

PLUG

28

723-11-28260

ORIFICE

29

702-21-55470

ORIFICE

30

01252-60520

BOLT

31

702-21-55480

FRANGE

32

07000-12020

O-RING

33

01252-61025

BOLT

34

07000-11010

O-RING

35

700-84-11730

BALL

36

702-21-55270

SEAT

37

702-21-55280

RETAINER

38

702-21-55290

SPRING
