Запчасти Komatsu PC75UU-3 МОТОР ХОДА (/) (КОНЕЧНАЯ ПЕРЕДАЧА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

21W-60-33200

MOTOR ASS'Y

|$3

TZ502D1000-01

FINAL ASS'Y

|$4

TZ500D1102-00

SPINDLE KIT

|$5

TZ500D1132-00

SPINDLE ASS'Y

1

SPINDLE

2

FLANGE

3

TZ500D1019-00

BOLT,REAMER

|$9

TZ500D1104-00

RV GEAR ASS'Y

|$10

TZ500D1204-00

RV GEAR KIT

4

RV GEAR

5

RV GEAR

6

SHAFT,CRANK

7

SPACER

8

BEARING

9

BEARING

|$17

TZ502D1107-00

SPUR GEAR KIT

10

SPUR GEAR

|$19

TZES20423232-B

FLOATING SEAL ASS'Y

11

SEAL,FLOATING (KIT)

12

TZ500D1001-00

HUB,MOTOR

13

TZ502D1006-00

GEAR

14

TZ500D1008-00

COVER

15

TZ500D1015-00

SHAFT

16

TZ500D1017-00

PIN

17

TZ810B1018-00

RING

18

TZ860A1013-00

SNAP RING SET

19

TZ500D1021-00

BEARING

20

TZJB2804-S19

RING,SNAP

21

04064-02512

RING,SNAP

22

07000-11008

O-RING (KIT)

23

07000-15230

O-RING (KIT)

24

TZJW1516-G35-5

O-RING (KIT)

25

TZ410D1033-01

PLUG

26

TZ810B2021-00

PLUG

27

07000-12014

O-RING (KIT)

28

04260-00952

BALL

29

TZJB1354-8-22

PIN

K

TZ505D9000-00

SEAL KIT

K

07000-11008

O-RING

K

07000-15230

O-RING

K

TZJW1516-G35-9

O-RING

K

TZES100-204-B

SEAL,FLOATING

K

07000-12014

O-RING

K

TZ15Z-22-42-10

SEAL,OIL

K

TZ500D2035-00

O-RING

K

TZ500D2039-00

O-RING

K

TZJB2401-P26-9

O-RING

K

07000-12018

O-RING

K

07002-12034

O-RING
