Запчасти Komatsu PC75UU-3 МОТОР ХОДА (/) (КОНЕЧНАЯ ПЕРЕДАЧА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21W-60-33100

TRAVEL MOTOR ASS'Y

|1

TZ971B1000-00

FINAL SUB ASS'Y

1

TZ810B1001-00

HUB

|2

TZ970B1102-00

SPINDLE KIT

2

TZ970B1132-00

SPINDLE ASS'Y

3

TZ910B1019-01

BOLT,REAMER

4

TZ192-230-30-A

FLOATING SEAL ASS'Y (KIT)

5

07000-15230

O-RING (KIT)

6

TZ810B1021-00

BEARING

|7

TZ970B1104-00

RV GEAR ASS'Y

7

TZ970B1204-00

RV GEAR (2 PIECES)

8

TZ910B1009-00

SHAFT,CRANK

9

TZ910B1012-00

SPACER

10

TZ910B1023-00

BEARING

11

TZ860A1022-00

BEARING

12

TZ860A1010-00

PIECE (12 KINDS)

13

TZ814B1107-00

SPUR GEAR KIT (3 PIECES)

14

TZ800B1014-00

PIECE,DISTANCE

15

04064-02512

RING,SNAP

16

TZ910B1016-00

SHAFT

17

04260-00952

BALL

18

TZ800A1015-00

JOINT

19

TZ814B1006-00

GEAR,INPUT

20

TZJB2804-S19

RING,SNAP

21

TZ810B1017-00

PIN

22

TZ810B1020-00

COLLAR

23

TZ821B1008-00

COVER

24

TZGM3-8

PLUG

25

TZJW1516-P74-9

O-RING (KIT)

26

TZ810B1018-00

RING

27

07000-11007

O-RING (KIT)

28

TZJW1516-G37-7

O-RING (KIT)

K

TZ971B9010-00

SEAL KIT

|K

07000-12011

O-RING

|K

TZ266B2039-00

O-RING

|K

TZ266B2035-00

O-RING

|K

TZ15Z-22-42-10

SEAL,OIL

|K

TZJB2401-P26-9

O-RING

|K

07000-12016

O-RING

|K

07002-02034

O-RING

|K

TZ192-230-30-A

FLOATING SEAL ASS'Y

|K

07000-15230

O-RING

|K

TZJW1516-P74-9

O-RING

|K

07000-11007

O-RING

|K

TZJW1516-G37-7

O-RING
