Запчасти Komatsu PC75UU-2E МОТОР ХОДА (/) (ГИДРАВЛ МОТОР) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21W-60-22130

TRAVEL MOTOR ASS'Y

|1

TZ920A200000XA

MOTOR ASS'Y,HYDRAULIC

1

TZ880A210100-D

FLANGE KIT,REAR

2

TZGM1-8

PLUG

3

TZ850A0006-00

PLATE¤ NAME

4

TZ810B2004-00

BLOCK,CYLINDER

5

TZ810B2105-00

PISTON KIT (9 PIECES)

6

TZ910B200300-X

PLATE,SWASH

7

TZ800B2032-00

PLATE,THRUST

8

TZ810B2007-00

PLATE,RETAINER

9

TZ810B2008-00

BOWL,THRUST

10

TZJB150625-238

PIN

11

TZ810B2014-00

SPRING

12

TZ880A2010-00

WASHER

13

TZ1RTW-42

RING

14

TZ800B2016-01

PLATE

15

TZ800A2015-00

PLATE

16

TZ880A2012-00

PISTON

17

TZSUN-2BG140

RING,BACK-UP (K1)

18

07000-12140

O-RING (K1)

19

TZJB1516-G28-9

O-RING (K1)

20

TZSUN-2WG28

RING,BACK-UP (K1)

21

TZ860A2009-01

PLATE,TIMING

22

06000-06203

BEARING

23

TZ880A2013-00

SPRING

24

TZ910B2002-00

SHAFT

25

TZ880A2029-00

BEARING

26

TZ15Z-22-42-10

SEAL,OIL (K1)

27

TZJB1501-22

BALL

28

TZJB1354-4-10

PIN

29

TZ860A2019-00

VALVE

30

TZ860A2020-01

SPRING

31

07000-11009

O-RING (K1)

32

TZ860A2018-00

SEAT

33

TZ100A2022-00

RING
