Запчасти Komatsu PC75UU-2 КАБИНА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

21W-54-00055

CAB ASS'Y

|1

21W-54-00054

CAB ASS'Y

|1

21W-54-00053

CAB ASS'Y

|1

21W-54-00052

CAB ASS'Y

|1

21W-54-00051

CAB ASS'Y

|1

21W-54-00050

CAB ASS'Y

1

CAB

|1

CAB

|1

CAB

2

20U-54-24752

WINDOW,L.H.¤ UPPER

|2

20U-54-24751

WINDOW,L.H.¤ UPPER

3

20U-54-24971

DAM

4

20U-54-25151

TRIM

5

20U-54-24761

WINDOW,L.H.¤ LOWER

6

20U-54-24981

DAM

7

21W-54-34770

WINDOW,REAR¤ LOWER (H502.8 X W566)

|7

20U-54-24772

WINDOW,REAR¤ LOWER (H502.8 X W586)

|7

20U-54-24771

WINDOW,REAR¤ LOWER (H502.8 X W586)

8

20U-54-24991

DAM

9

20U-54-25161

TRIM

|9

20U-54-25161

TRIM

9A

20U-54-25162

SEAL

10

20U-54-24860

LINING,REAR

11

20U-54-24871

LINING,L.H.

12

20U-54-24881

LINING,R.H.

13

20U-54-25540

COVER,REAR

14

20U-54-25170

SEAL

15

20T-54-75120

DUCT

16

21W-54-14690

CLIP

17

20U-54-24681

TAPE

|17

20U-54-24681

TAPE

18

20U-54-25510

SEAL

19

20U-54-25140

STOPPER

20

20U-54-25530

SHEET

21

20U-54-24711

GLASS

22

20U-54-24721

STRIP,WEATHER

23

20U-54-24732

WINDOW,UPPER

|23

20U-54-24731

WINDOW,UPPER

24

20U-54-24741

STRIP,WEATHER

25

20T-54-75210

GROMMET

26

08037-01008

GROMMET

27

08037-01610

GROMMET

28

09415-01008

CAP

|28

09415-01008

CAP

29

09415-00706

CAP

30

01220-40412

SCREW

31

01641-20405

WASHER

32

01220-40612

SCREW

33

01641-20608

WASHER

34

01370-00412

SCREW
