Запчасти Komatsu PC75UU-2 МОТОР ХОДА (/) (ГИДРАВЛ МОТОР) (ВТОР. ХОД СПЕЦ-Я.)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21W-60-22411

TRAVEL MOTOR ASS'Y

|1

TZ922B200001HT

MOTOR ASS'Y

1

TZ922B210100-H

FLANGE KIT,REAR

2

TZMB700-060

PLUG

3

TZGM1-8

PLUG

4

TZ121F2070-00

ORIFICE

5

TZGM1-4-K

PLUG

6

TZ850A0006-00

PLATE¤ NAME

7

04260-00793

BALL

8

TZ810B2004-00

BLOCK,CYLINDER

9

TZ810B2105-00

PISTON KIT (9 PIECES)

10

TZ910B200300-H

PLATE,SWASH

11

TZ800B2032-00

PLATE,THRUST

12

TZ810B2007-00

PLATE,RETAINER

13

TZ810B2008-00

BOWL,THRUST

14

TZJB150625-238

PIN

15

TZ810B2014-00

SPRING

16

TZ880A2010-00

WASHER

17

TZTH-R-42

RING,SNAP

18

TZ800A2016-00

PLATE

19

TZ800A2015-00

PLATE

20

TZ880A2012-00

PISTON

21

TZSUN-3BG140

RING,BACK-UP (K1)

22

07000-12140

O-RING (K1)

23

TZJW1516-G28-9

O-RING (K1)

24

TZSUN-3WG28

RING,BACK-UP (K1)

25

TZ860A2009-01

PLATE,TIMING

26

06000-06203

BEARING

27

TZ880A2013-00

SPRING

28

TZ910B2002-00

SHAFT

29

TZ880A2029-00

BEARING

30

TZ15Z-22-42-10

SEAL,OIL (K1)

31

TZ800B2070-01

PISTON ASS'Y

32

TZJB1501-22

BALL

33

TZJB1354-4-10

PIN

34

TZ860A2019-00

VALVE

35

TZ860A2020-01

SPRING

36

07000-11009

O-RING (K1)

37

TZ860A2018-00

SEAT,VALVE

38

TZ100A2022-00

RING

39

TZ200B2073-00

VALVE

40

TZ300B2043-01

SPRING

41

TZ300B2039-00

STOPPER

42

TZ300B2042-00

RING
