Запчасти Komatsu PC75UU-2 СТРЕЛА (БЕЗОПАСН. ОБОРУД-Е)(№798-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21W-70-21572

LEVER

2

01010-51020

BOLT

3

01643-31032

WASHER

|4

20U-70-21701

SENSOR ASS'Y,OFFSET

4

20U-70-21642

LEVER

|4

20U-70-21642

LEVER

5

04010-00310

KEY

|5

04010-00310

KEY

6

01010-50835

BOLT

|6

01010-50835

BOLT

7

01602-20825

WASHER,SPRING

|7

01602-20825

WASHER,SPRING

8

7861-92-8101

POTENTIOMETER

|8

7861-92-8101

POTENTIOMETER

|8

7861-92-8100

POTENTIOMETER

9

04205-10522

PIN

|9

04205-10522

PIN

10

01252-40625

BOLT

11

21W-06-22143

WIRING HARNESS

|11

21W-06-22210

WIRING HARNESS,(FOR TELESCOPIC ARM)

12

21W-70-21591

CUSHION

13

21W-70-21531

PLATE

14

01010-51230

BOLT

15

01643-31232

WASHER

16

20U-70-21770

BOLT

17

01643-31032

WASHER

18

203-06-56570

BAND

19

08036-01014

CLIP

20

01010-51016

BOLT

21

01643-31032

WASHER

22

08034-20823

BAND

23

21W-70-21652

BAR

|23

21W-70-21651

BAR

24

20U-70-21760

JOINT

25

21K-54-26370

BOLT

26

04250-81056

END

27

01583-11006

NUT

28

01010-51030

BOLT

29

01643-31032

WASHER

30

21W-06-22230

WIRING HARNESS,(FOR TELESCOPIC ARM)
