Запчасти Komatsu PC75UU-2 МОТОР ХОДА (/) (КОНЕЧНАЯ ПЕРЕДАЧА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC75UU-2 - МОТОР ХОДА (/) (КОНЕЧНАЯ ПЕРЕДАЧА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
4
5
6
7
7
8
8
9
9A
9A
10
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

Артикул

Название

Примечание

Количество

|$1

21W-60-22130

TRAVEL MOTOR ASS'Y

|$3

TZ922A1000-00

FINAL DRIVE ASS'Y

1

TZ810B1001-00

HUB

|$5

TZ920A1102-00

SPINDLE KIT

2

TZ920A1132-00

SPINDLE ASS'Y

3

TZ910B1019-01

BOLT,REAMER

|$8

TZ192-230-30-B

FLOATING SEAL ASS'Y (K1)

4

TZES100-192-B

SEAL,FLOATING

5

TZ860A1010-01

PIECE,DISTANCE

6

07000-15230

O-RING (K1)

7

TZ810B1021-00

BEARING

|$13

TZ910B1104-00

RV GEAR ASS'Y

8

TZ900B1204-00

RV GEAR (2 PIECES)

9

TZ910B1009-00

SHAFT,CRANK

9A

TZ910B1012-00

SPACER

10

TZ910B1023-00

BEARING

11

TZ860A1022-00

BEARING

12

TZ860A1013-00

SNAP RING SET (12 KINDS)

13

TZ814B1107-00

SPUR GEAR KIT (3 PIECES)

14

TZ800B1014-00

PIECE,DISTANCE

15

04064-02512

RING,SNAP

16

TZ910B1016-00

SHAFT

17

04260-00952

BALL

18

TZ800A1015-00

JOINT

19

TZ814B1006-00

GEAR,INPUT

20

TZJB2804-S19

RING,SNAP

21

TZ810B1017-00

PIN

22

TZ810B1020-00

COLLAR

23

TZ810B1008-00

COVER

24

TZGM3-8

PLUG

25

TZJW1516-P74-9

O-RING (K1)

26

TZ810B1018-00

RING

27

07000-11007

O-RING (K1)

28

TZJW1516-G35-9

O-RING (K1)

K1

TZ922A9000-00

SERVICE KIT

|$38

TZSUN-2BG140

RING,BACK-UP

|$39

07000-12140

O-RING

|$40

TZJB1516-G28-9

O-RING

|$41

TZSUN-2WG28

RING,BACK-UP

|$42

TZ15Z-22-42-10

SEAL

|$43

07000-11009

O-RING

|$44

TZJB2401-P26-9

O-RING

|$45

07000-12016

O-RING

|$46

07002-02034

O-RING

|$47

TZ192-230-30-B

FLOATING SEAL ASS'Y

|$48

07000-15230

O-RING

|$49

TZJW1516-P74-9

O-RING

|$50

07000-11007

O-RING

|$51

TZJW1516-G35-9

O-RING

Выбрано товаров: 49
