Запчасти Komatsu PC75US-3 P.P.C. ОСНОВН. ЛИНИЯ (/) (MONO СТРЕЛА) (БЕЗ ОТВАЛ) ГИДРАВЛИКА

1

21W-62-32490

HOSE¤ 1700MM,BROWN

2

21W-62-32650

HOSE¤ 1900MM,GREEN-WHITE

3

21W-62-32650

HOSE¤ 1900MM,YELLOW

4

21W-62-32660

HOSE¤ 2000MM,RED

5

21W-62-32660

HOSE¤ 2000MM,BLUE

6

20U-62-22180

NIPPLE

7

201-62-64680

NIPPLE

8

21W-62-31450

HOSE¤ 1600MM,YELLOW-RED

9

21W-62-32640

HOSE¤ 1800MM,GREEN

10

21W-62-32650

HOSE¤ 1900MM,WHITE

11

21W-62-32670

HOSE¤ 2200MM,BLUE

12

21W-62-32670

HOSE¤ 2200MM,BLACK

13

21W-62-32690

HOSE¤ 2900MM,BLUE-WHITE

14

20S-62-83120

HOSE¤ 1100MM,BLACK-GREEN

15

20U-62-22180

NIPPLE

16

201-62-64680

NIPPLE

17

206-06-61130

SWITCH

18

21W-62-32990

HOSE¤ 1400MM,BLACK-BLUE

19

21W-62-32210

HOSE¤ 1500MM,GREEN-RED

20

21W-62-32960

HOSE¤ 1900MM,ORANGE-YELLOW

21

21W-62-32960

HOSE¤ 1900MM,GREEN-YELLOW

22

21W-62-32960

HOSE¤ 1900MM,BROWN-YELLOW

23

21W-62-33110

HOSE¤ 1800MM,BLACK-YELLOW

24

08034-00519

BAND

25

08036-01414

CLIP

26

01010-81020

BOLT

27

01643-31032

WASHER
