Запчасти Komatsu PC75US-3 КОВШ (ВЕРТИКАЛЬН. ПАЛЕЦ¤ С РЕГУЛЯТОРОМ) КАТАЛОГИ ЗЧ

1

21W-920-2110

BUCKET,(760MM)

2

21W-920-2A20

PLATE (WELDED)

3

21W-920-2A50

PLATE,L.H. (WELDED)

4

21W-920-2A60

PLATE,R.H. (WELDED)

5

21W-70-24A30

PLATE (WELDED)

6

201-70-74161

PLATE (WELDED)

7

20X-70-23150

ADAPTER (WELDED)

8

20X-70-23160

TOOTH

9

203-70-43212

PIN

10

203-70-43220

PIN

11

201-70-74171

SIDE CUTTER,L.H.

12

201-70-74181

SIDE CUTTER,R.H.

13

21W-70-21810

BOLT

14

01803-02228

NUT

15

20X-70-24231

SPACER

16

201-70-74220

PLATE

17

20X-70-24250

PLATE¤ 0.5MM

18

01010-81260

BOLT

19

01643-31232

WASHER

20

175-30-16210

O-RING

21

135-70-13290

SPACER¤ 3.2MM

|21

135-70-13251

SPACER¤ 1.6MM

|21

201-70-22150

SPACER¤ 1.0MM

22

201-70-74111

BUCKET,(650MM)

23

201-70-74121

PLATE (WELDED)

24

21W-70-24A10

PLATE,L.H. (WELDED)

25

21W-70-24A20

PLATE,R.H. (WELDED)

26

21W-70-24A30

PLATE (WELDED)

27

201-70-74161

PLATE (WELDED)

28

20X-70-23150

ADAPTER (WELDED)

29

20X-70-23160

TOOTH

30

203-70-43212

PIN

31

203-70-43220

PIN

32

20X-70-24231

SPACER

33

201-70-74220

PLATE

34

20X-70-24250

PLATE¤ 0.5MM

35

01010-81260

BOLT

36

01643-31232

WASHER

37

175-30-16210

O-RING

38

135-70-13290

SPACER¤ 3.2MM

|38

135-70-13251

SPACER¤ 1.6MM

|38

201-70-22150

SPACER¤ 1.0MM
