Запчасти Komatsu PC75UD-3 ГЛАВН. КЛАПАН ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-21-09173

VALVE ASS'Y

|1

702-21-55100

VALVE ASS'Y,RELIEF

1

SLEEVE

2

COLLAR

3

FILTER

4

POPPET

5

SPRING

6

SCREW

7

NUT

8

O-RING

9

702-16-53920

O-RING

10

O-RING

11

07002-11623

O-RING

12

BLOCK

13

702-21-55310

VALVE

14

702-21-55460

SPRING

15

702-21-55420

O-RING

16

702-21-55520

O-RING

17

702-21-55440

O-RING

18

702-21-53120

FILTER

19

07000-11009

O-RING

20

702-21-55330

SPRING

21

702-21-55380

PLATE

22

702-21-55410

PLATE

23

01252-60820

BOLT

24

01643-50823

WASHER

25

702-21-55530

O-RING

26

BLOCK

27

702-21-55511

SPOOL

28

702-21-55640

SPRING

29

702-21-55620

PLUG

30

07002-11423

O-RING

31

702-21-55710

SEAT

32

702-21-55720

SPRING

33

04260-00793

BALL

34

07000-11009

O-RING

35

PLUG

36

723-11-28260

ORIFICE

37

702-21-55470

ORIFICE

38

01252-60520

BOLT

39

702-21-55480

FRANGE

40

07000-12020

O-RING

41

01252-61025

BOLT

42

07000-11010

O-RING

43

700-84-11730

BALL

44

702-21-55270

SEAT

45

702-21-55280

RETAINER

46

702-21-55290

SPRING
