Запчасти Komatsu PC75UD-2 КОВШ (ВЕРТИКАЛЬН. ПАЛЕЦ¤ С РЕГУЛЯТОРОМ)(№7-) КАТАЛОГИ ЗЧ

|1

201-70-00860

BUCKET ASS'Y

|1

21W-70-00480

BUCKET ASS'Y

1

201-70-74111

BUCKET,(650MM)

|1

21W-70-24110

BUCKET,(650MM)

2

21W-70-24A10

PLATE,L.H. (WELDED)

3

21W-70-24A20

PLATE,R.H. (WELDED)

4

201-70-74121

PLATE (WELDED)

5

201-70-74161

PLATE (WELDED)

6

21W-70-24A30

PLATE (WELDED)

7

20X-70-23150

ADAPTER (WELDED)

8

20X-70-23160

TOOTH

9

203-70-43212

PIN

10

203-70-43220

PIN

11

201-70-74171

SIDE CUTTER,L.H.

|11

20X-933-1110

SIDE CUTTER,L.H.

12

201-70-74181

SIDE CUTTER,R.H.

|12

20X-933-1120

SIDE CUTTER,R.H.

13

21W-70-21810

BOLT

14

01803-02228

NUT

15

201-70-74230

PIN

16

20X-70-24231

SPACER

17

201-70-74220

PLATE

18

20X-70-24250

PLATE¤ 0.5MM

19

175-30-16210

O-RING

20

01010-51260

BOLT

21

01643-31232

WASHER

22

201-70-74240

PIN

23

201-70-74260

PIN

24

201-70-74254

RING

25

201-70-74274

RING

26

135-70-13290

SPACER¤ 3.2MM

27

135-70-13251

SPACER¤ 1.6MM

28

201-70-22150

SPACER¤ 1.0MM
