Запчасти Komatsu PC75UD-2 ГУСЕНИЦЫ КАТАЛОГИ ЗЧ

Схема запчастей Komatsu PC75UD-2 - ГУСЕНИЦЫ КАТАЛОГИ ЗЧ
1
2
3
4
5
6
7
7
8
9
10
10
11
1
2
3
1
2
3
1
2
3
2
3
2
3
6
8
9
11
6
8
9
11
12

Артикул

Название

Примечание

Количество

|1

21W-32-01002

TRACK SHOE ASS'Y

1

201-32-51110

SHOE,TRACK

2

201-32-51211

BOLT¤ SHOE (KIT)

3

112-32-11221

NUT¤ SHOE (KIT)

|4

21W-32-00011

TRACK LINK ASS'Y

4

201-32-51120

LINK,TRACK¤ L.H.

5

201-32-51130

LINK,TRACK¤ R.H.

6

201-32-51140

BUSHING,REGULAR

7

101-32-11271

SEAL,DUST¤ REGULAR

8

21W-32-11150

PIN,REGULAR

9

101-32-11173

BUSHING,MASTER

10

101-32-11281

SEAL,DUST¤ MASTER

11

21W-32-11190

PIN,MASTER

|1

21W-32-02500

TRACK SHOE ASS'Y,RUBBER GROUSER

1

201-32-51360

SHOE¤ TRACK,RUBBER GROUSER

2

201-32-51211

BOLT¤ SHOE (KIT)

3

112-32-11221

NUT¤ SHOE (KIT)

|4

21W-32-00011

TRACK LINK ASS'Y

|1

21W-32-02100

TRACK SHOE ASS'Y,RUBBER PAD

1

21W-32-26110

SHOE¤ TRACK

2

01252-31440

BOLT,SHOE (KIT)

3

01580-01411

NUT,SHOE (KIT)

|4

21W-32-00012

TRACK LINK ASS'Y

|1

21W-32-02400

TRACK SHOE ASS'Y,TRIPLE GROUSER (FOR CITY PAD)

1

201-32-71420

SHOE¤ TRACK,CITY PAD

2

201-32-51211

BOLT¤ SHOE (KIT)

3

112-32-11221

NUT¤ SHOE (KIT)

|4

21W-32-00012

TRACK LINK ASS'Y

|2

201-32-05021

SHOE BOLT AND NUT K.

2

201-32-51211

BOLT¤ SHOE

3

112-32-11221

NUT¤ SHOE

|2

21W-32-05000

SHOE BOLT AND NUT K.

2

01252-31440

BOLT

3

01580-01411

NUT

6

101-98-09113

BUSHING,REGULAR

8

21W-98-09010

PIN,REGULAR

9

101-98-09142

BUSHING,MASTER

11

21W-98-09030

PIN,MASTER

6

101-98-09133

BUSHING,REGULAR

8

21W-98-09020

PIN,REGULAR

9

101-98-09162

BUSHING,MASTER

11

21W-98-09040

PIN,MASTER

12

21W-32-25110

SHOE,RUBBER

Выбрано товаров: 43
