Запчасти Komatsu PC75UD-2 МОТОР ПОВОРОТА (/)(№-797) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7T-00230

SWING MOTOR ASS'Y

1

708-7T-51130

CASE

2

708-7T-51510

COVER,END

3

708-7T-51210

O-RING

4

720-68-19610

PIN

5

01010-51045

BOLT

6

708-7T-52120

SHAFT

7

708-7T-12240

BEARING

8

708-7T-12250

BEARING

9

708-7T-12230

SEAL,OIL

10

04065-04518

RING,SNAP

11

708-7T-05020

SPACER KIT

|11

SPACER¤ 1.6MM

|11

SPACER¤ 1.7MM

|11

SPACER¤ 1.8MM

|11

SPACER¤ 1.9MM

|11

SPACER¤ 2.0MM

|11

SPACER¤ 2.1MM

|11

SPACER¤ 2.2MM

12

708-7T-53420

PLATE,THRUST

13

708-7T-53511

GUIDE,RETAINER

14

708-7T-13560

SPRING

15

708-7T-13530

WASHER

16

708-7T-13540

PIN

17

04065-03815

RING,SNAP

18

708-7T-53350

PISTON SUB ASS'Y

19

708-7T-13342

RETAINER,SHOE

20

708-7T-53130

BLOCK,CYLINDER

21

708-7T-53212

PLATE,VALVE

22

706-73-72420

VALVE

23

706-73-72440

SPRING

24

706-73-72430

PLUG

25

07002-12434

O-RING

26

708-7T-52512

PLATE

27

708-7T-52520

DISC

28

708-7T-55140

PISTON,BRAKE

29

07000-12130

O-RING

30

708-7T-55220

O-RING

31

708-7T-55150

SPRING

32

702-73-04100

RELIEF VALVE ASS'Y
