Запчасти Komatsu PC75R-2 USA СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC75R-2 USA - СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ
29
29
31
20
21
32
24
22
40
36
18
33
19
16
34
28
44
27
28
38
26
35
37
11
23
30
1
12
13
15
17
14
45
44
45
43
41
42
39
A
B
C
D
E
A
A

Артикул

Название

Примечание

Количество

\0

22E-01-11401

ENGINE, ASSY.

1

YM129907-42000

PUMP, ASSY.

11

YM129900-42020

GASKET

12

YM26106-060302

BOLT

13

YM26106-080552

BOLT

14

YM129930-42400

PULLEY

15

YM25152-004400

V-BELT

16

YM119620-49290

COCK

17

YM129981-44760

SPACER

18

YM124465-44950

GASKET

19

YM129907-49800

THERMOSTAT, ASSY.

20

YM129916-49530

COVER, THERMOSTAT

21

YM121850-49540

GASKET

22

YM121850-49550

GASKET

23

YM129907-49730

SUPPORT

24

YM121850-49810

THERMOSTAT

26

YM105582-59150

BOLT, PIPE JOINT

27

YM23387-040800

JOINT

28

YM23414-080000

GASKET

29

YM23875-030000

PLUG

30

YM26106-060122

BOLT

31

YM26106-060202

BOLT

32

YM129900-49870

GASKET

33

YM23414-080000

GASKET

34

YM26106-080122

BOLT

35

YM26106-080602

BOLT

36

YM121450-42450

PLUG

37

YM121250-44901

WATER TEMPERATURE TRANSMITTER (ALARM)

38

YM124465-44950

GASKET

39

YM129907-49610

PIPE, ASSY.

40

YM129907-49710

PIPE

41

YM129907-49750

PROTECTION, PIPE

42

YM124722-59050

CLAMP

43

YM129907-49620

PIPE, ASSY.

44

YM129907-49720

PIPE

45

YM124722-59050

CLAMP

Выбрано товаров: 36
