Запчасти Komatsu PC75R-2 USA МОТОР ПОВОРОТА (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

708-7T-00381

SWING MOTOR, ASSY.

\0

708-7T-01150

MOTOR, ASSY.

1

708-7T-11240

CASE, MOTOR

2

708-7T-11640

COVER

3

708-7T-51210

O-RING

4

720-68-19610

PIN

5

01010-81250

BOLT

6

708-7T-12220

SHAFT

7

708-7T-12240

BEARING

8

708-7T-12250

BEARING

9

708-7T-05020

SPACER KIT

9

SPACER 1.6 mm

9

SPACER 1.7 mm

9

SPACER 1.8 mm

9

SPACER 1.9 mm

9

SPACER 2.0 mm

9

SPACER 2.1 mm

9

SPACER 2.2 mm

10

708-7T-12230

GASKET

11

04065-04518

RING, SNAP

12

708-7T-13140

BLOCK, CYLINDER

13

708-7T-13270

TIMING PLATE

14

720-68-19610

PIN

15

708-7T-13540

PIN

16

708-7T-13530

WASHER

17

708-7T-13570

SPRING

18

04065-03815

RING, SNAP

19

708-7T-13510

GUIDE

20

708-7T-13342

PLATE

21

708-7T-13611

PISTON, ASSY.

22

708-7T-13421

THRUST PLATE

23

708-7T-13710

SPACER

24

708-7T-52512

DISK

25

708-7T-15120

FRICTION DISK

26

708-7T-15140

PISTON

27

07000-12310

O-RING

28

708-7T-55220

O-RING

29

708-7T-15150

SPRING
