Запчасти Komatsu PC75R-2 USA БОКОВ. КРЫШКА ДВИГ. ЧАСТИ КОРПУСА И КАБИНА

1

22E-54-11670

HOOD

2

01010-51025

BOLT

3

01643-31032

WASHER

4

21D-54-11590

GASKET

5

22E-54-11330

GASKET

6

22E-54-11320

GASKET

7

22E-54-11680

COVER

8

01010-50840

BOLT

9

01643-30823

WASHER

10

22E-54-11690

GASKET

11

22E-54-11710

SUPPORT

12

21D-54-11560

HINGE

13

22E-54-11640

SHIM

14

21D-54-11660

SHIM

15

01010-50820

BOLT

16

21D-54-11190

DAMPER

17

21D-09-85140

PIN, COTTER

18

22E-54-11720

HOOD

18

22E-54-11721

HOOD

19

21D-54-11710

GASKET

20

20M-54-72250

CATCH

21

226-54-11150

PUSH-BUTTON, ASSY.

21

22E-54-11650

PUSH-BUTTON, ASSY.

22

22E-54-11660

SPACER

23

01252-40640

SCREW

24

01580-10605

NUT

25

226-54-11130

PUSH-BUTTON, ASSY.

26

21D-09-15150

SCREW

27

01580-10806

NUT

28

22E-54-11260

SUPPORT

29

21D-54-11260

PIN

30

01643-31232

WASHER

31

22E-54-11270

NUT

32

22E-46-11430

TOOL BOX, ASSY.

33

21D-46-11310

PROTECTION

34

21D-46-11220

SHEET

35

22E-06-11950

HORN

36

01435-00825

BOLT

37

01643-30823

SPRING WASHER

38

21D-09-21440

NUT

39

01010-51020

BOLT

40

21D-54-11750

GASKET

41

21D-54-11740

GASKET
