Запчасти Komatsu PC75R-2 USA ГИДРОЛИНИЯ (КЛАПАН PPCЛИНИЯ ПОДАЧИ) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

702-21-09192

SERVOCONTROL FEED UNIT, ASSY.

2

01253-41020

SCREW

3

21D-09-69620

O-RING

4

21D-62-15790

PRESSURE TAKE-UP

5

21D-09-86220

GASKET

6

21D-09-59130

REDUCTION

7

22E-09-11220

UNION

8

21D-09-69960

O-RING

9

21D-09-97490

HOSE

10

21D-09-51640

ELBOW

11

21D-09-69970

O-RING

12

21D-60-11170

FILTER, ASSY.

13

21D-60-11220

CARTRIDGE

14

21D-60-11250

KIT, GASKET

15

22E-62-12230

UNION

16

21D-09-69970

O-RING

17

21D-09-86220

GASKET

18

22E-62-12220

VALVE

19

21D-09-86280

GASKET

20

22E-62-12210

BLOCK

21

01010-50820

BOLT

22

01643-30823

WASHER

23

21D-60-17310

ACCUMULATOR

24

21D-09-73200

WASHER

25

21D-09-61560

UNION

26

21D-09-73190

GASKET

27

21D-09-54730

PLUG

28

21D-09-86280

GASKET

29

21D-09-51630

ELBOW

30

21D-09-69910

O-RING

31

21D-09-97430

HOSE

32

21D-09-51620

ELBOW

33

21D-09-69960

O-RING

34

21D-09-51190

UNION

35

21D-09-69910

O-RING
