Запчасти Komatsu PC75R-2 USA ГИДРОЛИНИЯ (ЛИНИЯ ПОДАЧИ) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

723-29-11202

CONTROL VALVE, ASSY.

2

01010-51435

BOLT

3

01643-31445

WASHER

4

22E-62-12520

PLUG

5

21D-09-69830

O-RING

6

22E-62-12530

PLUG

7

21D-09-69960

O-RING

8

226-62-11310

FLANGE

9

21D-09-69660

O-RING

10

01252-41030

SCREW

11

21D-09-73700

SPRING WASHER

12

21D-09-69860

O-RING

13

226-09-11230

HOSE

14

226-62-11330

UNION

15

21D-09-69220

O-RING

16

21D-09-69660

O-RING

17

226-09-11420

HOSE

18

226-09-12410

UNION

19

21D-09-69660

O-RING

20

226-62-11320

FLANGE

21

21D-09-69660

O-RING

22

01252-40835

SCREW

23

01643-30823

SPRING WASHER

24

21D-09-69120

O-RING

25

21D-09-58340

TEE

26

21D-09-69960

O-RING

27

21D-09-59130

REDUCTION

28

21D-62-15790

PRESSURE TAKE-UP

29

21D-09-86220

GASKET

30

21D-09-92250

HOSE

31

22E-09-11610

ELBOW

32

21D-09-69960

O-RING

33

226-09-12110

ELBOW

34

21D-09-69660

O-RING

35

226-09-12910

FLANGE

36

21D-09-69660

O-RING

37

01252-41060

SCREW

38

21D-09-69130

O-RING
