Запчасти Komatsu PC75R-2 МОТОР ХОДА (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

Схема запчастей Komatsu PC75R-2 - МОТОР ХОДА (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
22
49
48
50
27
47
34
30
5
28
24
36
23
52
32
25
35
33
19
29
20
26
17
7
37
53
41
36
4
28
30
1
34
51
37
27
3
5
6
3
8
38
2
25
26
29
33
12
14
13
15
16
10
11
43
18
21
18
39
31
55
40
54
42
9
56
45
55
46
54
44

Артикул

Название

Примечание

Количество

\0

978B0000-00-NG

FINAL DRIVE, ASSY.

\0

TZ971B200000NG

TRAVEL MOTOR, ASSY.

\0

TZ971B210100-G

FLANGE KIT

1

FLANGE

2

SPOOL

3

TZGM1-8

PLUG

4

TZ512B2021-00

PLUG

5

TZGDL1-16-S

PLUG

6

ORIFICE

7

FILTER

8

TZ850A0006-00

PLATE

9

TZ910B2002-00

SHAFT

10

TZ844B200300-N

SWASH PLATE

11

TZ920B2004-00

CYLINDER BLOCK

\11

TZ810B2105-00

KIT, PISTON

12

PISTON, ASSY.

13

PISTON

14

SLIDER

15

TZ920B2007-00

RETAINER PLATE

16

TZ810B2008-00

THRUST BALL

17

TZ860A2009-01

TIMING PLATE

18

TZ880A2010-00

SPACER

19

TZ266B2012-00

PISTON

20

TZ970B2013-00

SPRING

21

TZ810B2014-00

SPRING

22

TZ800A2015-00

FRICTION DISK

23

TZ800A2016-00

DISK

24

TZ100A2021-00

PLUG

25

TZ860A2051-00

PLUG

26

TZ869A2052-00

SEAT

27

TZ860A2053-02

PLUG

28

TZ860A2054-01

VALVE

29

TZ860A2056-00

SPRING

30

TZ860A2055-01

SPRING

31

TZ15Z-22-42-10

SNAP RING

32

TZ266B2035-00

O-RING

33

TZJB2401-P26-9

O-RING

34

07000-12016

O-RING

35

TZ266B2039-00

O-RING

36

TZJB1354-4-10

PARALLEL PIN

37

TZJB1354-8-25

PARALLEL PIN

38

01252-31030

SCREW

39

TZTH-R-42

RING, SNAP

40

TZ880A2029-00

BEARING

41

06000-06203

BEARING

42

TZJB150625-238

ROLLER

43

TZ970B2032-00

THRUST PLATE

44

TZ844B2070-01

PISTON, ASSY.

45

PISTON

46

SLIDER

47

TZ200B2073-00

VALVE

48

TZ300B2039-00

RETAINER

49

TZ300B2042-00

RING, SNAP

50

TZ300B2043-01

SPRING

51

04260-00793

BALL

52

07002-02034

O-RING

53

07000-12011

O-RING

54

TZ263B2076-02

PIVOT

55

TZ263B2077-01

PARALLEL PIN

56

TZ844B2085-00

SPRING

Выбрано товаров: 60
