Запчасти Komatsu PC75R-2 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

21D-54-12303

OPERATOR'S CAB, ASSY.

1

21D-54-13430

SEAL

2

21D-54-13661

FRAME, FRONT

3

21D-54-13680

SEAL, FRONT UPPER

4

21D-54-13670

GLASS, FRONT, UPPER

5

21D-54-13440

GLASS, FRONT, LOWER

6

21D-54-13630

BLOCK

7

21D-54-13640

RABBET

8

21D-54-13650

GASKET

9

01010-50816

BOLT

10

01643-30823

WASHER

11

21D-54-13731

LEVER, R.H.

12

21D-54-13741

LEVER, L.H.

13

21D-54-13790

CYLINDER

14

21D-09-23160

NUT

15

21D-54-13761

PIN

16

21D-54-13770

WASHER

17

01010-51012

BOLT

18

21D-54-13780

COVER

19

21D-54-13750

BUSHING

20

21D-54-13690

BUSHING

21

21D-54-13480

SPRING

22

21D-54-13720

LEVER

23

21D-54-13710

PIN

24

21D-54-14120

STRIKER

25

01643-31032

WASHER

26

01010-50616

BOLT

27

21D-09-73490

SPRING WASHER

28

21D-54-13580

WASHER

29

21D-54-13590

BLOCK

30

21D-54-13610

GASKET

31

21D-54-13620

SPACER

32

01010-50825

BOLT

33

21D-54-13450

LATCH ASSY., R.H.

33

21D-54-13520

LATCH ASSY., L.H.

34

21D-54-13530

LATCH

35

21D-54-13480

SPRING

36

21D-54-13460

PIN

37

21D-54-13470

SLEEVE

38

21D-54-13490

PIN

39

21D-54-13510

KNOB

40

21D-54-14670

PLATE

41

21D-54-14680

HANDLE, R.H.

42

21D-54-14690

HANDLE, L.H.

43

01010-50820

BOLT

44

21D-09-74460

WASHER

45

21D-09-86190

COVER

46

01580-10806

NUT

47

21D-54-14710

PIN

48

21D-54-12110

KNOB
