Запчасти Komatsu PC75R-2 СТАРТЕР ДВИГАТЕЛЬ
A
22
1
19
17
20
21
16
3
12
4
14
11
5
10
18
9
15
13
6
8
7
2
№
Артикул
Название
Примечание
Количество
\0
22E-01-11000
MOTOR, ASSY.
1
YM129900-77010
STARTER MOTOR
2
YM129900-77400
ROTOR,ASSY.
3
YM129900-77440
COIL ASSY.,FIELD
4
YM129900-77450
BRUSH (+)
5
YM171008-77450
SCREW
6
YM129900-77460
COVER, REAR
7
YM129900-77480
HOLDER BRUSH, ASSY.
8
YM129900-77500
BRUSH (--)
9
YM129900-77510
PINION, ASSY.
10
YM129900-77520
CLUTCH, ASSY.
11
YM171008-77730
BEARING
12
YM171008-77740
BEARING
13
YM129900-77540
SHAFT
14
YM129900-77550
STOPPER KIT
15
YM129900-77610
RETAINER
16
YM129900-77590
SWITCH, MAGNETIC
17
YM129900-77620
LEVEL SET
18
YM129900-77640
BOLT
19
YM129900-77650
PAN ASSY., DUST
20
YM129900-77710
HOUSING
21
YM171008-77750
COVER
22
YM26116-120302
BOLT
Выбрано товаров: 23
