Запчасти Komatsu PC75R-2 ПОВОРОТН. БЛОК РАБОЧЕЕ ОБОРУДОВАНИЕ

1

22E-70-11110

BRACKET, ASSY.

2

21D-09-31110

BUSHING

3

21D-09-67130

GASKET

4

21D-09-43320

PIN

5

21D-09-39120

SHIM

6

01010-51235

BOLT

7

01643-31232

WASHER

8

21D-70-14170

SPACER

9

21D-09-43120

PIN

10

201-70-23140

SHIM

11

21D-09-43330

PIN

12

21D-09-39110

SHIM

13

22E-70-11120

PIN

14

21D-09-15190

SCREW

15

21D-70-14160

FITTING

16

21D-70-14130

PIN

17

01010-51640

BOLT

18

21D-09-74540

SPRING WASHER

19

21D-09-39170

SPACER

20

21D-09-39160

SPACER

21

21D-09-44110

PIN

22

201-70-23140

SHIM

23

21D-70-14150

PLATE

24

01010-51030

BOLT

25

01643-31032

WASHER

26

22E-46-11350

UNION

27

21D-04-11450

COTTER

28

22E-46-11360

UNION

29

22E-46-11370

ELBOW

30

22E-46-11380

HOSE

31

21D-09-89140

FITTING

1

22E-70-11110

BRACKET, ASSY.

2

21D-09-31110

BUSHING

3

21D-09-67130

GASKET

4

21D-09-43320

PIN

5

21D-09-39120

SHIM

6

01010-51235

BOLT

7

01643-31232

WASHER

8

21D-70-14170

SPACER

9

21D-09-43120

PIN

10

201-70-23140

SHIM

11

21D-09-43330

PIN

12

21D-09-39110

SHIM

13

22E-70-11120

PIN

14

21D-09-15190

SCREW

15

21D-70-14160

FITTING

16

21D-70-14130

PIN

17

01010-51640

BOLT

18

21D-09-74540

SPRING WASHER

19

21D-09-39170

SPACER

20

21D-09-39160

SPACER

21

21D-09-44110

PIN

22

201-70-23140

SHIM

23

21D-70-14150

PLATE

24

01010-51030

BOLT

25

01643-31032

WASHER

26

22E-46-11350

UNION

27

21D-04-11450

COTTER

28

22E-46-11360

UNION

29

22E-46-11370

ELBOW

30

22E-46-11380

HOSE

31

21D-09-89140

FITTING
