Запчасти Komatsu PC75R-2 РЕГУЛЯТОР ДВИГАТЕЛЬ

\0

22E-01-11000

MOTOR, ASSY.

\0

YM129980-51000

PUMP, ASSY.

\0

REGULATOR, ASSY.

1

YMX0292016010

NUT

2

YMX1540006400

HOUSING

3

YMX0296325070

O-RING

4

YMX1540072900

PLUG

5

YMX1540070200

ADAPTOR

6

YMX0200181840

BOLT

7

YMX1543501900

PLATE

8

YMX0290106810

BOLT

9

YMX1540100100

SCREW

10

YMX1540110100

NUT

11

YMX1540132320

BOLT

12

YMX0141108440

SPRING WASHER

13

YMX1545001020

COVER

14

YMX1543210400

BUSHING

15

YMX1540313000

SCREW

16

YMX1392060600

NUT

17

YMX1540360300

PLUG

18

YMX0201065040

BOLT

19

YMX1540100200

SCREW

20

YMX0201063840

BOLT

21

YMX1530205220

LIMITER

22

YMX1540635100

COVER

23

YMX0290206260

BOLT

24

YMX0290206260

BOLT

25

YMX0200062040

BOLT

26

YMX0200061640

BOLT

27

YMX1541010020

WEIGHT ASSY., GOVERNOR

28

YMX0258031610

KEY

29

YMX0293212020

SPRING WASHER

30

YMX0292312030

NUT

31

YMX1541230120

SLEEVE

32

YMX0293110010

SHIM

32

YMX0293110180

SHIM

32

YMX0293110190

SHIM

32

YMX0293110210

SHIM

32

YMX1394100000

SHIM, 0.500 mm

32

YMX1394100100

SHIM, 1.500 mm

32

YMX1394103000

SHIM, 2.000 mm

32

YMX1394103100

SHIM, 3.000 mm

\32

YMX1394103200

SHIM, 4.000 mm

41

YMX1541502900

SPRING

42

YMX1541540701

SPRING

43

YMX1541580920

CAPSULE

44

YMX1540111700

NUT

45

YMX0265121540

GASKET

46

YMX1541591200

NUT

47

YMX1541856120

SPRING

48

YMX0292016080

NUT

49

YMX1542006920

LINK

50

YMX1542043000

BUSHING

51

YMX0296318020

O-RING

52

YMX0160101640

RING, SNAP

53

YMX1396110000

GASKET

54

YMX1394110000

SHIM

55

YMX0293111070

SHIM

56

YMX1542043100

BUSHING

57

YMX0258031310

KEY

58

YMX1542062800

COLLAR

59

YMX1542060200

SPRING WASHER

60

YMX1542163820

LINK

61

YMX1542303920

LINK

62

YMX0160100540

RING, SNAP

63

YMX1542364100

LINK

64

YMX1542370100

PIN

65

YMX1543960620

LEVER

66

YMX1543827920

LEVER

67

YMX0200061640

BOLT

68

YMX1543142600

SPRING

69

YMX0296310030

O-RING

70

YMX1543220100

CAP

71

YMX1543265020

LINK

72

YMX1543277400

SPRING

73

YMX0293110520

SHIM

73

YMX0293110530

SHIM, 0.250 mm

73

YMX0293110540

SHIM, 0.300 mm

73

YMX0293110550

SHIM, 0.350 mm

73

YMX0293110560

SHIM, 0.400 mm

\73

YMX0293110570

SHIM, 0.500 mm

79

YMX1543507700

GASKET

80

YMX1543507800

GASKET

81

YMX0296352020

O-RING

82

YMX0265061040

GASKET

83

YMX1540351600

NUT

84

YMX1543587200

SUPPORT

85

YMX0265182240

GASKET

86

YMX1541883320

SPRING
