Запчасти Komatsu PC750SE-6K-J МОТОР ХОДА (БЛОК ЦИЛИНДРОВ И ПОРШЕНЬ В СБОРЕ)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
209-60-73504
MOTOR ASS'Y
|1
209-60-73503
MOTOR ASS'Y
|1
209-60-73502
MOTOR ASS'Y
|1
209-60-73501
MOTOR ASS'Y
|1
KBB011B-12006
CYLINDER BLOCK ASS'Y
|1
KB2046B-61214
CYLINDER BLOCK ASS'Y
|1
KB2046B-61213
CYLINDER BLOCK ASS'Y
1
CYLINDER BLOCK
|1
CYLINDER BLOCK
|1
CYLINDER BLOCK ASS'Y
2
KBB0111-23002
PLATE¤ VALVE
|2
PLATE¤ VALVE
|2
PLATE¤ VALVE
3
PISTON ASS'Y
|4
KB2046B-61006
RETAINER PLATE ASS'Y
|4
KB2046B-61004
RETAINER PLATE ASS'Y
4
PLATE¤ RETAINER
5
HOLDER¤ RETAINER
|5
HOLDER¤ RETAINER
6
KB20461-67421
SHAPAN
7
KB20461-62006
CASE¤ OIL SEAL
8
KB20461-66904
BEARING¤ ROLLER
9
KB20461-60401
BEARING¤ NEEDLE
10
KB20461-61601
RACE¤ INNER
11
KB20461-61801
COLLAR
12
KB20461-61315
SPRING
13
KB20461-70802
PIN
|13
KB20461-70801
PIN
14
KB20461-69301
WASHER
15
KB20461-68604
RING¤ SNAP
16
KB20461-68602
RING¤ SNAP
17
KB20461-68605
RING¤ SNAP
18
KB92703-16500
BOLT¤ SOCKET HEAD
19
KB20461-62104
SEAL¤ OIL (K1)
20
KB20461-65213
O-RING (K1)
21
KB95123-11500
O-RING (K1)
22
KB20461-69409
PISTON¤ BRAKE
23
KB20461-69603
PLATE¤ FRICTION
24
KB20461-69602
PLATE¤ FRICTION
25
KB20461-69503
PLATE¤ DISK
26
KB20461-61314
SPRING
27
KB20941-63109
O-RING (K1)
28
KB95113-01000
O-RING (K1)
29
KB15096-01010
PLUG
30
KB20461-61311
SPRING
31
KB20461-69205
BALL¤ STEEL
32
KB20461-42401
PLUG
33
KB95113-01400
O-RING (K1)
34
KB20461-65104
RING¤ BACK-UP (K1)
35
KB20461-65105
RING¤ BACK-UP (K1)
36
KB95113-03400
O-RING (K1)
37
KB95113-02000
O-RING (K1)
K1
KB2046A-65125
REPAIR KIT
|1
KB95113-01800
O-RING
|1
KB95113-00500
O-RING
|1
KB95712-00500
RING¤ BACK-UP
|1
KB95113-00600
O-RING
|1
KB95712-00600
RING¤ BACK-UP
|1
KB95113-01000
O-RING
|1
KB95113-01200
O-RING
|1
KB95113-01800
O-RING
|1
KB95113-02100
O-RING
|1
KB21001-00182
O-RING
|1
KB95712-01200
RING
|1
KB95712-01800
RING
|1
KB95713-02100
RING¤ BACK-UP
|1
KB95113-01100
O-RING
|1
KB95113-01800
O-RING
|1
KB20461-65213
O-RING
|1
KB20461-62104
SEAL¤ OIL
|1
KB20461-65213
O-RING
|1
KB95123-11500
O-RING
|1
KB20941-63109
O-RING
|1
KB95113-01000
O-RING
|1
KB95113-01400
O-RING
|1
KB20461-65104
RING¤ BACK-UP
|1
KB20461-65105
RING¤ BACK-UP
|1
KB95113-03400
O-RING
|1
KB95113-02000
O-RING
Выбрано товаров: 79
