Запчасти Komatsu PC750SE-6K-J BM ЦИЛИНДР(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ700

CYLINDER GROUP,L.H. (FINAL COATING)

G-1

209-63-X2303

BOOM CYLINDER GROUP,L.H.

G-1

209-63-X2301

BOOM CYLINDER GROUP,L.H.

G-2

707-01-XZ710

CYLINDER GROUP,R.H. (FINAL COATING)

G-2

209-63-X2313

BOOM CYLINDER GROUP,R.H.

G-2

209-63-X2311

BOOM CYLINDER GROUP,R.H.

|1

209-63-02302

CYLINDER ASS'Y

|1

209-63-02301

CYLINDER ASS'Y

1

209-63-53142

CYLINDER

|1

209-63-53141

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-27-20630

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14630

RING,BUFFER (KIT)

7

707-52-91150

BUSHING

8

198-63-93170

SEAL,DUST (KIT)

9

07179-14160

RING,SNAP

10

07000-15195

O-RING (KIT)

11

07001-05195

RING,BACK-UP (KIT)

12

07000-15195

O-RING (KIT)

13

07001-05195

RING,BACK-UP (KIT)

14

707-71-31410

COLLAR

15

707-71-31580

COLLAR

16

707-71-11450

RING

17

01011-82705

BOLT

18

01643-32780

WASHER

19

209-63-53121

ROD,PISTON

|19

209-63-53120

ROD,PISTON

20

707-46-11520

BUSHING

21

07043-00108

PLUG

22

707-36-20300

PISTON

23

07000-12115

O-RING (KIT)

24

707-35-52860

RING,BACK-UP (KIT)

25

707-44-20910

RING

26

707-39-20820

RING,WEAR (KIT)

27

707-44-20180

RING,PISTON (KIT)

28

707-40-20870

SPACER

29

707-71-51490

PLUNGER

30

01252-61460

BOLT

31

209-63-53171

TUBE,L.H.

|31

209-63-53271

TUBE,R.H.

32

209-62-58180

TUBE,L.H.

|32

209-62-58190

TUBE,R.H.

33

07000-13038

O-RING (KIT)

34

01010-81245

BOLT

35

01643-31232

WASHER

36

07378-11210

HEAD

37

07371-51260

FLANGE

38

01010-81245

BOLT

39

01643-31232

WASHER

40

707-88-96110

BAND

41

707-88-96121

BRACKET

|41

707-88-96120

BRACKET

42

01010-81240

BOLT

43

01643-31232

WASHER

44

07283-33442

CLIP

45

01599-01011

NUT

46

01643-31032

WASHER

|K

707-99-77380

SERVICE KIT
