Запчасти Komatsu PC750SE-6K-01 ОСНОВН. НАСОС (7/9) (NO. НАСОС)(№K-K999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-00620

PUMP ASS'Y

|1

708-25-09170

VALVE ASS'Y,SERVO

|1

708-23-00421

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15130

SEAT

5

708-25-25130

SPRING

6

708-25-55250

SPRING

7

708-23-15120

SEAT

8

708-23-15160

PLUG

9

07000-02018

O-RING

10

708-25-15150

COVER

11

01580-10806

NUT

12

708-25-15320

BOLT

13

01602-20619

WASHER

14

708-25-15171

PLUG

15

07002-02034

O-RING

16

07239-12009

NUT

17

708-25-15180

SLEEVE

18

708-25-15280

SPOOL

19

708-25-15310

SPRING

20

708-25-15330

SPACER

21

708-25-15430

PLUG

22

708-25-15340

SCREW

23

07000-02012

O-RING

24

708-25-15250

COVER

25

01580-10806

NUT

26

708-25-15320

BOLT

27

01602-20619

WASHER

28

708-25-15260

PLUG

29

07002-00823

O-RING

30

708-25-15270

ARM

31

708-25-15360

PIN

32

708-25-15370

WASHER

33

708-25-15380

E-RING

34

07040-11007

PLUG

35

07002-01023

O-RING

36

708-25-55110

PLATE

37

07000-02011

O-RING

38

01010-80825

BOLT

39

720-68-11920

FILTER

40

07000-12010

O-RING

41

07000-11009

O-RING

42

708-25-19150

ORIFICE

43

708-25-19290

PLUG

44

01643-50823

WASHER

45

07000-03048

O-RING

46

720-68-11920

FILTER

47

708-25-15460

SHIM¤ 0.05MM

|47

708-25-15470

SHIM¤ 0.10MM
