Запчасти Komatsu PC750SE-6 ОХЛАЖД-Е (РАДИАТОР И ЧАСТИ КОРПУСА)(№-8) СИСТЕМА ОХЛАЖДЕНИЯ

|1

209-03-71101

RADIATOR ASS'Y

1

209-03-71121

TANK

2

209-03-71170

CAP

3

209-03-71110

CORE

4

209-03-71131

TANK

5

209-03-71220

PLATE

6

209-03-71231

PLATE

7

209-03-71240

PLATE

8

209-03-71790

PLATE

9

209-03-71260

GASKET

10

01010-81030

BOLT

11

01602-21030

WASHER

12

209-03-71161

BRACKET

13

01010-81235

BOLT

14

01602-21236

WASHER

15

209-03-71141

SUPPORT

16

209-03-71151

SUPPORT

17

01010-81235

BOLT

18

01643-31232

WASHER

19

07730-50004

VALVE

20

209-03-71270

SHEET

21

209-03-71280

SHEET

22

209-03-71210

OIL COOLER

23

01010-81225

BOLT

24

01643-31232

WASHER

25

6212-62-4100

AFTER COOLER ASS'Y

26

01010-81240

BOLT

27

01643-31232

WASHER

28

209-03-71412

SHROUD

|28

209-03-71411

SHROUD

29

209-03-71551

BRAKER,WIND

30

01010-81230

BOLT

31

01643-31232

WASHER

32

01010-81650

BOLT

33

01643-31645

WASHER

34

07283-31079

CLIP

35

01599-01214

NUT

36

01643-31232

WASHER
