Запчасти Komatsu PC750SE-6 NO. НАСОС (СОЕДИНИТ. ЧАСТИ) (СО СЪЕМОМ ПРОТИВОВЕСА)(№9-) ГИДРАВЛИКА

1

708-2L-00630

PUMP ASS'Y

2

706-87-40150

PLUG

3

20B-27-11210

BLEEDER

4

07002-02434

O-RING

5

207-62-33950

NIPPLE

6

07002-11423

O-RING

7

20Y-62-25810

TEE

8

07002-11423

O-RING

9

209-62-57210

TEE

10

07002-12434

O-RING

11

07235-10311

ELBOW

12

07002-11423

O-RING

13

07235-10628

ELBOW

14

07002-12434

O-RING

15

21T-62-29960

TEE

16

07002-11423

O-RING

17

209-62-78760

HOSE, 250MM

18

114-62-23210

ELBOW

19

07002-12434

O-RING

20

20Y-62-22820

BAND, BLUE

21

201-62-72370

HOSE

22

07000-15230

O-RING

23

01010-81650

BOLT

24

01643-31645

WASHER

25

209-62-79590

BLOCK

26

01010-81075

BOLT

27

01643-31032

WASHER

28

799-101-5220

NIPPLE

29

07002-11023

O-RING

30

21T-09-11460

O-RING

31

07371-31049

FLANGE

32

07372-21035

BOLT

33

01643-51032

WASHER

|$40

209-64-13600

VALVE ASS'Y,(SEE FIG.Y1872-01A0)

|$41

209-62-79600

VALVE ASS'Y

34

BLOCK

35

209-62-75220

SHAFT

36

07000-13048

O-RING

37

07001-03048

RING

38

07000-13042

O-RING

39

07001-03042

RING

40

04025-00412

PIN

41

20Y-970-3350

FLANGE

42

207-60-31730

PIN

43

01010-81025

BOLT

44

01010-81040

BOLT

45

01643-31032

WASHER

46

01011-81000

BOLT

47

01643-31032

WASHER

48

799-101-5220

NIPPLE

49

07002-11023

O-RING

50

21T-09-11460

O-RING

51

07371-31049

FLANGE

52

07372-21035

BOLT

53

01643-51032

WASHER
