Запчасти Komatsu PC750SE-6 ЦИЛИНДР РУКОЯТИ(ДЛЯ 7.M СТРЕЛА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY041

CYLINDER GROUP,L.H. (FINAL COATING)

G-1

707-01-XY040

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XY051

CYLINDER GROUP,R.H. (FINAL COATING)

G-2

707-01-XY050

CYLINDER GROUP,R.H. (FINAL COATING)

|$9

707-01-0A531

CYLINDER ASS'Y

|$10

707-01-0A530

CYLINDER ASS'Y

1

707-13-18611

CYLINDER

1

707-13-18610

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-27-18960

HEAD,CYLINDER

6

707-51-12030

PACKING,ROD (KIT)

7

707-51-12640

RING,BUFFER (KIT)

8

707-52-90980

BUSHING

9

195-63-93170

SEAL,DUST (KIT)

10

07179-13136

RING,SNAP

11

07000-15175

O-RING (KIT)

12

707-35-91840

RING,BACK-UP (KIT)

13

07000-15175

O-RING (KIT)

14

707-35-91840

RING,BACK-UP (KIT)

15

707-71-32940

COLLAR

16

01011-82400

BOLT

17

707-88-75410

WASHER

18

707-58-12331

ROD,PISTON

18

707-58-12330

ROD,PISTON

19

707-76-11130

BUSHING

20

07145-00110

SEAL,DUST (KIT)

21

07043-00108

PLUG

22

707-36-18520

PISTON

23

07000-15110

O-RING (KIT)

24

07001-05110

RING,BACK-UP (KIT)

25

707-44-18920

RING

26

707-39-18830

RING,WEAR (KIT)

27

707-44-18280

RING,PISTON (KIT)

28

707-71-70330

PLUNGER

29

04260-00952

BALL

30

707-71-91230

CAP

31

707-71-61320

PLUNGER

32

01310-01225

SCREW

33

707-86-11681

TUBE,L.H.

33

707-86-11680

TUBE,L.H.

33

707-86-11691

TUBE,R.H.

33

707-86-11690

TUBE,R.H.

34

07000-13035

O-RING (KIT)

35

01435-01055

BOLT

36

707-88-95800

BAND

37

707-88-95810

BRACKET

38

209-63-63391

BRACKET

39

01010-81240

BOLT

40

01643-51232

WASHER

41

07283-23442

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

44

07000-13038

O-RING

45

07378-11210

HEAD

46

07371-51260

FLANGE

47

01010-81245

BOLT

48

01643-31232

WASHER

49

07000-13032

O-RING

50

707-88-84710

PLATE

51

01010-81030

BOLT

52

01643-51032

WASHER

|$69

707-99-68660

SERVICE KIT
