Запчасти Komatsu PC750SE-6 ОСНОВН. НАСОС (/8) (NO. НАСОС)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2L-00750

PUMP ASS'Y

|$3

708-25-09860

SERVO VALVE ASS'Y,REAR

|$4

708-25-09660

VALVE ASS'Y,CO + NC

|$5

708-23-00441

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-17460

PLUG

4

708-25-17430

SCREW

5

07000-02010

O-RING

6

708-25-17131

COVER

7

01580-10806

NUT

8

708-25-17141

SPOOL

9

708-25-17150

SLEEVE

10

708-25-17160

PISTON

11

708-25-17170

COVER

12

07000-02014

O-RING

13

708-25-17180

SEAT

14

708-25-17690

SPRING

15

708-25-17451

SLEEVE

16

708-25-17220

PISTON

17

708-25-17370

SEAT

18

708-25-17250

SPRING

19

708-25-17470

SEAT

20

708-25-17480

PISTON

21

708-25-17380

PLUG

22

07000-03028

O-RING

23

07000-02021

O-RING

24

708-23-17240

COVER

25

708-23-17290

COVER

26

708-25-15340

SCREW

27

706-75-40310

BOLT

28

01602-20619

WASHER

29

708-25-15320

BOLT

30

01602-20619

WASHER

31

01580-10806

NUT

32

07000-02012

O-RING

33

07000-12012

O-RING

34

07001-02012

RING,BACK-UP

35

708-25-15320

BOLT

36

01602-20619

WASHER

37

07000-12021

O-RING

38

07001-02021

RING,BACK-UP
