Запчасти Komatsu PC750LC-7K ЦИЛИНДР КОВША (ДЛЯ .M РУКОЯТЬ) (PC7LC) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

209-63-K1190

CYLINDER ASS'Y

1

209-63-K1210

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-27-18660

HEAD,CYLINDER

6

707-51-12030

PACKING,ROD (KIT)

7

707-51-12630

RING,BUFFER (KIT)

8

707-52-90950

BUSHING

9

195-63-93170

SEAL,DUST (KIT)

10

07179-13136

RING,SNAP

11

07000-15180

O-RING (KIT)

12

07001-05180

RING,BACK-UP (KIT)

13

07000-15180

O-RING (KIT)

14

07001-05180

RING,BACK-UP (KIT)

15

707-71-31420

COLLAR

16

707-71-31281

COLLAR

17

209-63-56160

RING

18

01011-82400

BOLT

19

707-88-75410

WASHER

20

209-63-K1220

ROD,PISTON

21

707-76-11130

BUSHING

22

07145-00110

SEAL,DUST (KIT)

23

07043-00108

PLUG

24

707-71-61300

PLUNGER

25

07000-12100

O-RING (KIT)

26

707-35-52940

RING,BACK-UP (KIT)

27

707-36-18500

PISTON

28

707-44-18920

RING

29

707-39-18830

RING,WEAR (KIT)

30

707-44-18280

RING,PISTON (KIT)

31

707-40-18870

SPACER

32

01252-31455

BOLT

33

209-63-K1230

TUBE

34

209-63-73582

TUBE

35

07000-13035

O-RING (KIT)

36

01010-81060

BOLT

37

01643-51032

WASHER

38

707-88-21050

BAND

39

707-88-21060

BAND

40

707-88-22031

BRACKET

41

209-63-73592

BRACKET

42

01010-81240

BOLT

43

01643-51232

WASHER

44

07283-23442

CLIP

45

01599-01011

NUT

46

01643-31032

WASHER

47

07378-11210

HEAD,(FOR SHIPPING)

48

07000-13038

O-RING,(FOR SHIPPING)

49

07371-51260

FLANGE,(FOR SHIPPING)

50

01010-81245

BOLT,(FOR SHIPPING)

51

01643-31232

WASHER,(FOR SHIPPING)

|K

707-99-68510

SERVICE KIT,BUCKET CYLINDER
