Запчасти Komatsu PC750LC-6K-01 ЛЕВ. КРЫШКА(КАБИНА)(№K-) ЧАСТИ КОРПУСА

1

209-54-77511

FRAME

2

20Y-54-28170

BRACKET

3

01010-81230

BOLT

4

01643-31232

WASHER

5

205-54-51970

DOVE TAIL

6

01010-80616

BOLT

7

01643-30623

WASHER

8

209-54-74490

BRACKET

9

01010-81230

BOLT

10

01643-31232

WASHER

11

209-54-63260

BRACKET

12

01010-81230

BOLT

13

01643-31232

WASHER

14

20Y-54-11611

STOPPER

15

01580-11008

NUT

16

209-54-K1850

COVER

17

198-54-41982

LOCK ASS'Y (WELDED)

18

203-54-32260

STOPPER

19

20Y-54-28161

HINGE (WELDED)

20

01010-81230

BOLT

21

01643-31232

WASHER

22

205-54-53550

DOVE TAIL

23

01010-80616

BOLT

24

01643-30623

WASHER

25

20Y-54-29232

BAR

26

20B-54-12210

SPRING

27

01023-10408

SCREW

28

209-54-K1860

COVER

29

198-54-41982

LOCK ASS'Y (WELDED)

30

20Y-54-28161

HINGE (WELDED)

31

01010-81230

BOLT

32

01643-31232

WASHER

33

205-54-53550

DOVE TAIL

34

01010-80616

BOLT

35

01643-30623

WASHER

36

20Y-54-29232

BAR

37

20B-54-12210

SPRING

38

01023-10408

SCREW

39

01010-81230

BOLT

40

01643-31232

WASHER

41

07049-01215

PLUG

42

01010-81230

BOLT

43

01643-31232

WASHER

44

209-54-74681

SHEET

45

209-54-74821

SHEET

46

209-54-74831

SHEET

47

209-53-11660

SHEET

48

209-53-11670

SHEET

49

209-53-11680

SHEET

50

209-54-74681

SHEET
