Запчасти Komatsu PC750LC-6 МОТОР ХОДА (КОРПУС И ЗАДН. КРЫШКА)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

209-60-73504

MOTOR ASS'Y

|$1

209-60-73503

MOTOR ASS'Y

|$2

KB2046B-62112

CASE ASS'Y

1

CASE

2

VALVE ASS'Y

|$5

COVER ASS'Y

3

KBB0441-37002

COVER, REAR

|$7

KB20463-60909

VALVE ASS'Y

4

BODY

5

SPOOL

6

FILTER

7

SPOOL

8

SPRING

9

GUIDE

10

PLUG

11

PLUG

12

O-RING (K1)

13

WASHER

14

O-RING (K1)

15

RING, BACK-UP (K1)

16

O-RING (K1)

17

RING, BACK-UP (K1)

18

RING, SNAP

19

KB92703-08450

BOLT, SOCKET HEAD

20

KB95113-01000

O-RING (K1)

21

KB20941-46115

ORIFICE

|$26

KB21963-50174

RELIEF VALVE ASS'Y

22

SEAT

23

HOUSING

24

POPPET

25

SEAT

26

SPRING

27

PLUG

28

GUIDE

29

SCREW

30

NUT

31

PISTON

32

O-RING (K1)

33

O-RING (K1)

34

O-RING (K1)

35

O-RING (K1)

36

RING (K1)

37

RING (K1)

38

RING, BACK-UP (K1)

39

KB20461-32422

PLUG

40

PLUG,(FOR SHIPPING)

41

KB20461-52406

PLUG

42

KB95113-01100

O-RING (K1)

43

KB95113-01800

O-RING (K1)

44

KB20461-65213

O-RING (K1)

45

KB20941-46111

ORIFICE

46

KB20461-60213

SHAFT
