Запчасти Komatsu PC750LC-6 ЦИЛИНДР РУКОЯТИ(ДЛЯ 8.M СТРЕЛА)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ590

CYLINDER GROUP,(FINAL COATING)

G-1

209-63-X2381

ARM CYLINDER GROUP

|$3

209-63-02381

CYLINDER ASS'Y

1

209-63-63541

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-27-20630

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14630

RING,BUFFER (KIT)

7

707-52-91150

BUSHING

8

198-63-93170

SEAL,DUST (KIT)

9

07179-14160

RING,SNAP

10

07000-15195

O-RING (KIT)

11

07001-05195

RING,BACK-UP (KIT)

12

07000-15195

O-RING (KIT)

13

07001-05195

RING,BACK-UP (KIT)

14

707-71-31440

COLLAR

15

707-71-31580

COLLAR

16

707-71-11450

RING

17

01011-82705

BOLT

18

01643-32780

WASHER

19

209-63-63520

ROD,PISTON

20

707-46-11520

BUSHING

21

07043-00108

PLUG

22

707-36-20300

PISTON

23

07000-12115

O-RING (KIT)

24

707-35-52860

RING,BACK-UP (KIT)

25

707-44-20910

RING

26

707-39-20820

RING,WEAR (KIT)

27

707-44-20180

RING,PISTON (KIT)

28

707-40-20870

SPACER

29

707-71-60310

PLUNGER

30

04260-01270

BALL

31

707-71-91050

SCREW

32

707-71-51490

PLUNGER

33

01252-31460

BOLT

34

209-63-63571

TUBE

35

07000-13038

O-RING (KIT)

36

01010-51280

BOLT

37

01643-31232

WASHER

38

707-88-96110

BAND

39

707-88-96130

BAND

40

01010-51240

BOLT

41

01643-31232

WASHER

42

07283-34346

CLIP

43

01599-01011

NUT

44

01643-31032

WASHER

45

07000-13048

O-RING

46

07378-11410

HEAD

47

07371-51470

FLANGE

48

01010-41455

BOLT

49

01643-31445

WASHER

|$54

707-99-77380

SERVICE KIT
