Запчасти Komatsu PC750LC-6 OLSS ЛИНИЯ(№-8) ГИДРАВЛИКА

1

07108-20314

HOSE

2

07108-20317

HOSE

3

203-62-62790

HOSE, 1300MM

4

20Y-62-22790

BAND, RED

5

20Y-62-22810

BAND, YELLOW

6

20Y-62-22820

BAND, BLUE

7

20Y-62-22830

BAND, WHITE

8

20Y-62-22850

BAND, GREEN

9

20Y-62-15950

CLIP

10

01010-81230

BOLT

11

01643-31232

WASHER

12

07108-20313

HOSE

12A

08034-00414

BAND

12B

20Y-62-22810

BAND, YELLOW

12C

20Y-62-22820

BAND, BLUE

13

101-04-12250

CLIP ASS'Y

14

01010-81230

BOLT

15

01643-31232

WASHER

16

08034-00536

BAND

17

08034-00536

BAND

18

07108-20311

HOSE

18A

08034-00414

BAND

18B

20Y-62-22790

BAND, RED

18C

20Y-62-22830

BAND, WHITE

19

195-33-11220

SPACER

20

01010-81250

BOLT

21

01643-31232

WASHER

22

201-62-72320

HOSE, 300MM

23

07102-20406

HOSE

24

209-62-77940

HOSE, 600MM
