Запчасти Komatsu PC750LC-6 КАБИНА (ПЕРЕДН. ОКНА)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$48

209-54-00360

OPERATOR'S CAB ASS'Y

|$49

207-54-00350

OPERATOR'S CAB ASS'Y

|$51

20Y-54-36705

FRONT WINDOW ASS'Y

1

20Y-54-36713

WINDOW

2

20Y-54-38122

GLASS

3

20Y-54-38133

WEATHER STRIP

4

20Y-54-38143

SEAL

5

20Y-54-38152

SEAL

6

20Y-54-43130

LATCH ASS'Y

7

20Y-54-43140

LATCH ASS'Y

8

01435-40816

BOLT

9

20Y-54-14290

STOPPER

10

01580-11008

NUT

11

20Y-54-14590

HANDLE

12

01023-10616

SCREW

13

20Y-54-14310

STRIKER

14

20Y-54-14280

SCREW

15

20Y-54-37810

STOPPER

16

01023-70416

SCREW

17

20Y-54-37820

STOPPER

18

01023-70416

SCREW

19

20Y-54-36835

BLOCK

20

20Y-54-36845

BLOCK

21

01252-50635

BOLT

22

01641-50608

WASHER

23

20Y-54-39152

ROLLER

24

205-54-63310

LOCK ASS'Y

25

01435-40820

BOLT

26

20Y-54-39363

BRACKET

27

01435-40820

BOLT

28

154-61-16570

WASHER

29

08074-40000

SWITCH

30

20Y-54-39590

WIRING HARNESS

31

20Y-54-36150

GROMMET

32

08051-00801

CLIP

33

20Y-54-14721

LOCK

34

01435-40820

BOLT

|$88

20Y-54-36103

LOWER WINDOW ASS'Y

35

20Y-54-36122

LATCH ASS'Y,R.H.

36

20Y-54-36132

LATCH ASS'Y,L.H.

37

20Y-54-36142

PLATE

38

08037-01610

GROMMET

39

01225-70612

SCREW

40

20Y-54-36211

COVER

41

20Y-54-36113

GLASS

42

20Y-54-36171

SEAT

43

20Y-54-36230

SHIM, 2.0MM

44

01370-00620

SCREW

45

01643-30623

WASHER

46

20Y-54-36182

STOPPER

47

01435-40820

BOLT
