Запчасти Komatsu PC750-7 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC750-7 - МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
9
10
10
11
12
13
13
14
15
16
16
17
17
18
18
19
19
20
21
22
22
22
23
23
23
24
24
25
26
27
28
28
29

Артикул

Название

Примечание

Количество

|$1

209-60-75101

MOTOR ASS'Y

|$2

KBB0443-13089

BASE ASS'Y

|$3

VALVE ASS'Y (K2)

1

SPOOL (K2)

2

SPOOL (K2)

3

FILTER (K2)

4

O-RING (K1)(K2)

5

O-RING (K1)(K2)

6

RING, BACK-UP (K1)(K2)

7

RING, BACK-UP (K1)(K2)

8

RING, SNAP (K2)

9

KB95113-00700

O-RING (K1)

10

ORIFICE (K2)

11

KBB0111-13112

SPRING

12

KB20461-52406

PLUG

13

KB95113-01800

O-RING (K1)

14

KBB0441-14003

GUIDE

15

KB20461-42414

PLUG

16

KB21961-60301

VALVE

17

KB21961-60412

SPRING

18

KB21961-95014

PLUG

19

KB95113-02900

O-RING (K1)

20

ORIFICE (K2)

21

ORIFICE (K2)

22

KB20461-32422

PLUG

23

KB95113-01100

O-RING (K1)

24

KB97171-06241

PLUG (K2)

25

KB21961-40811

ORIFICE (K2)

26

KB20461-70802

PIN

27

KBB0111-13074

SPRING

28

KB20361-40845

PIN

29

KB92703-18500

BOLT

K1

KBB044A-51158

SEAL KIT

1

KB95113-01400

O-RING

1

KB95113-00800

O-RING

1

KB95123-04000

O-RING

1

KB95113-01200

O-RING

1

KB95113-01800

O-RING

1

KB95113-02100

O-RING

1

KB21001-00182

O-RING

1

KB95712-01200

RING

1

KB95712-01800

RING

1

KB95713-02100

RING, BACK-UP

1

KB95113-00600

O-RING

1

KB95113-00500

O-RING

1

KB95712-00600

RING, BACK-UP

1

KB95712-00500

RING, BACK-UP

1

KB95113-00700

O-RING

1

KB95113-01800

O-RING

1

KB95113-02900

O-RING

1

KB95113-01100

O-RING

K2

KBB044B-23139

PLATE, BASE, KIT

1

KBB0441-79049

BASE

1

KBB0853-02036

SPOOL ASS'Y

1

KBB0443-09043

VALVE ASS'Y

1

KB21961-10802

ORIFICE

1

KBB0111-85005

ORIFICE

1

KBB0111-85001

ORIFICE

1

KB97171-06241

PLUG

1

KB21961-40811

ORIFICE

Выбрано товаров: 60
