Запчасти Komatsu PC750-7 ЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX880

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XX890

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0E470

CYLINDER ASS'Y

1

707-13-18670

CYLINDER

2

707-46-11510

BUSHING

3

07043-00108

PLUG

4

707-27-18970

HEAD,CYLINDER

5

707-51-13030

PACKING,ROD (KIT)

6

707-51-13640

RING,BUFFER (KIT)

7

707-52-91070

BUSHING

8

707-56-13520

SEAL,DUST (KIT)

9

07179-14146

RING

10

07000-15175

O-RING (KIT)

11

707-35-91840

RING,BACK-UP (KIT)

12

01011-82400

BOLT

13

707-88-75410

WASHER

14

707-58-13180

ROD,PISTON

15

707-46-11510

BUSHING

16

07043-00108

PLUG

17

707-36-18530

PISTON

18

07000-15120

O-RING (KIT)

19

07001-05120

RING,BACK-UP (KIT)

20

707-44-18920

RING

21

707-39-18830

RING,WEAR (KIT)

22

707-44-18280

RING,PISTON (KIT)

23

01310-01225

SCREW

24

209-62-74610

TUBE,L.H.

24

209-62-74590

TUBE,R.H.

25

07000-13038

O-RING (KIT)

26

01435-01245

BOLT

27

707-88-21090

BAND

28

209-62-74620

BRACKET

29

209-63-78160

BRACKET

30

01435-01235

BOLT

31

07283-23442

CLIP

32

01597-01009

NUT

33

01643-31032

WASHER

34

07282-03411

CLAMP

35

01435-01016

BOLT

36

07000-13038

O-RING

37

07378-11210

HEAD

38

07371-51260

FLANGE

39

01010-81245

BOLT

40

01643-31232

WASHER

|$48

707-99-69690

SERVICE KIT
