Запчасти Komatsu PC750-7-M1 ОСНОВН. КЛАПАН (5-СЕКЦИОНН.) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

709-15-93800

CONTROL VALVE

|1

BODY GROUP ASS'Y

1

BLOCK

2

709-14-11820

PLATE

3

709-12-11411

VALVE,CHECK

4

709-12-11430

SPRING

5

07000-13048

O-RING

6

709-12-12440

PLATE

7

01010-81250

BOLT

8

01643-51232

WASHER

9

709-14-11750

PISTON

10

709-14-11760

SEAL

10A

709-14-12280

POPPET

11

709-14-11771

POPPET

12

709-14-11850

POPPET

13

709-14-12290

POPPET

14

709-14-11790

SPRING

15

708-8E-16160

PLUG

16

07002-11023

O-RING

17

01011-81210

BOLT

18

07000-12018

O-RING

19

PLUG

20

709-10-91310

SLEEVE

21

706-73-70140

VALVE,CHECK

22

706-73-70150

SPRING

23

709-74-92450

PLUG

24

709-74-92460

NUT

25

700-93-11320

O-RING

26

700-93-11330

RING,BACK-UP

27

07000-12010

O-RING

28

07001-02010

RING
