Артикул
Название
Примечание
Количество
G-1
209-63-X3360
CYLINDER GROUP,BOTTOM DUMP¤ L.H.
G-1
209-63-X3370
CYLINDER GROUP,BOTTOM DUMP¤ R.H.
|1
209-63-03360
CYLINDER ASS'Y,BOTTOM DUMP
1
209-63-96740
CYLINDER
2
207-63-76170
BUSHING
3
07145-00090
SEAL,DUST (KIT)
4
07043-00108
PLUG,GREASE
5
707-27-14650
HEAD,CYLINDER
6
195-63-94170
SEAL,DUST (KIT)
7
07179-13104
RING,SNAP
8
707-52-90650
BUSHING
9
707-51-90030
PACKING,ROD (KIT)
10
707-51-90630
RING,BUFFER (KIT)
11
07000-15135
O-RING (KIT)
12
07001-05135
RING,BACK-UP (KIT)
13
01010-81875
BOLT
14
707-41-11840
WASHER
15
209-63-96720
ROD,PISTON
16
707-76-90040
BUSHING
17
07145-00090
SEAL,DUST (KIT)
18
07043-00108
PLUG,GREASE
19
707-36-14620
PISTON
20
707-40-13670
SPACER
21
01252-61240
BOLT
22
707-44-14180
RING,PISTON (KIT)
23
707-39-14820
RING,WEAR (KIT)
24
707-44-14910
RING
25
07000-12070
O-RING (KIT)
26
707-35-52910
RING,BACK-UP (KIT)
27
209-63-96770
TUBE,L.H.
|27
209-63-96870
TUBE,R.H.
28
209-62-53620
TUBE,L.H.
|28
209-62-53630
TUBE,R.H.
29
07000-13035
O-RING (KIT)
30
01010-81060
BOLT
31
01643-31032
WASHER
32
209-62-53670
BRACKET
33
209-62-53660
BAND
34
01010-81035
BOLT
35
01643-31032
WASHER
36
07282-03411
CLAMP
37
01010-81020
BOLT
38
01643-31032
WASHER
39
07378-11000
HEAD
40
07371-31049
FLANGE
41
07000-13032
O-RING
42
07372-21035
BOLT
43
01643-51032
WASHER
|K
707-99-56200
SERVICE KIT
Выбрано товаров: 49
