Запчасти Komatsu PC750-6 ЦИЛИНДР КОВША (SALTY МЕСТН. СПЕЦ-Я.)(№-8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

209-63-X6370

BUCKET CYLINDER G.

|1

209-63-06370

CYLINDER ASS'Y

1

209-63-77940

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-27-18560

HEAD,CYLINDER

6

707-51-12030

PACKING,ROD (KIT)

7

707-51-12630

RING,BUFFER (KIT)

8

707-52-90950

BUSHING

9

707-56-12080

SEAL,DUST (KIT)

10

707-75-12520

RING

11

07000-15180

O-RING (KIT)

12

07001-05180

RING,BACK-UP (KIT)

13

07000-15180

O-RING (KIT)

14

07001-05180

RING,BACK-UP (KIT)

15

707-71-31420

COLLAR

16

707-71-31281

COLLAR

17

209-63-56160

RING

18

01011-82400

BOLT

19

707-88-75410

WASHER

20

209-63-77920

ROD,PISTON

21

707-76-11130

BUSHING

22

07145-00110

SEAL,DUST (KIT)

23

07043-00108

PLUG

24

707-36-18500

PISTON

25

07000-12100

O-RING (KIT)

26

707-35-52940

RING,BACK-UP (KIT)

27

707-44-18920

RING

28

707-39-18830

RING,WEAR (KIT)

29

707-44-18280

RING,PISTON (KIT)

30

707-40-18870

SPACER

31

707-71-61300

PLUNGER

32

01252-61455

BOLT

33

209-63-77970

TUBE

34

209-63-77980

TUBE

35

07000-13035

O-RING (KIT)

36

01010-81060

BOLT

37

01643-51032

WASHER

38

07000-13038

O-RING

39

07378-11210

HEAD

40

07371-51260

FLANGE

41

01010-71245

BOLT

42

01643-31232

WASHER

43

707-88-21030

BAND

44

707-88-21140

BAND

45

707-88-22260

BRACKET

46

209-63-77990

BRACKET

47

01010-81240

BOLT

48

01643-51232

WASHER

49

07283-23442

CLIP

50

01599-01011

NUT

51

01643-31032

WASHER

|K

707-99-68550

SERVICE KIT
