Запчасти Komatsu PC750-6 НИЖН. ГИДРОЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.)(№-9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

209-63-X3360

CYLINDER GROUP,BOTTOM DUMP, L.H.

G-1

209-63-X3370

CYLINDER GROUP,BOTTOM DUMP, R.H.

|$3

209-63-03360

CYLINDER ASS'Y,BOTTOM DUMP

1

209-63-96740

CYLINDER

2

207-63-76170

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07043-00108

PLUG,GREASE

5

707-27-14650

HEAD,CYLINDER

6

195-63-94170

SEAL,DUST (KIT)

7

07179-13104

RING,SNAP

8

707-52-90650

BUSHING

9

707-51-90030

PACKING,ROD (KIT)

10

707-51-90630

RING,BUFFER (KIT)

11

07000-15135

O-RING (KIT)

12

07001-05135

RING,BACK-UP (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

209-63-96720

ROD,PISTON

16

707-76-90040

BUSHING

17

07145-00090

SEAL,DUST (KIT)

18

07043-00108

PLUG,GREASE

19

707-36-14620

PISTON

20

707-40-13670

SPACER

21

01252-61240

BOLT

22

707-44-14180

RING,PISTON (KIT)

23

707-39-14820

RING,WEAR (KIT)

24

707-44-14910

RING

25

07000-12070

O-RING (KIT)

26

707-35-52910

RING,BACK-UP (KIT)

27

209-63-96770

TUBE,L.H.

27

209-63-96870

TUBE,R.H.

28

209-62-53620

TUBE,L.H.

28

209-62-53630

TUBE,R.H.

29

07000-13035

O-RING (KIT)

30

01010-81060

BOLT

31

01643-31032

WASHER

32

209-62-53670

BRACKET

33

209-62-53660

BAND

34

01010-81035

BOLT

35

01643-31032

WASHER

36

07282-03411

CLAMP

37

01010-81020

BOLT

38

01643-31032

WASHER

39

07378-11000

HEAD

40

07371-31049

FLANGE

41

07000-13032

O-RING

42

07372-21035

BOLT

43

01643-51032

WASHER

|$50

707-99-56200

SERVICE KIT
