Запчасти Komatsu PC750-6 ЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

209-63-X3340

CYLINDER GROUP,L.H.

G-1

209-63-X3350

CYLINDER GROUP,R.H.

|$3

209-63-03340

CYLINDER ASS'Y

1

209-63-78140

CYLINDER

2

707-46-11510

BUSHING

3

07043-00108

PLUG

4

707-27-18670

HEAD,CYLINDER

5

707-51-13030

PACKING,ROD (KIT)

6

707-51-13630

RING,BUFFER (KIT)

7

707-52-91050

BUSHING

8

707-56-13520

SEAL,DUST (KIT)

9

07179-14146

RING

10

07000-15180

O-RING (KIT)

11

07001-05180

RING,BACK-UP (KIT)

12

01011-82400

BOLT

13

707-88-75410

WASHER

14

209-63-78120

ROD,PISTON

15

707-46-11510

BUSHING

16

07043-00108

PLUG

17

707-36-18510

PISTON

18

07000-12110

O-RING (KIT)

19

707-35-52950

RING,BACK-UP (KIT)

20

707-44-18920

RING

21

707-39-18830

RING,WEAR (KIT)

22

707-44-18280

RING,PISTON (KIT)

23

707-40-18880

SPACER

24

01252-61455

BOLT

25

209-63-78170

TUBE,L.H.

25

209-63-78270

TUBE,R.H.

26

209-62-53440

TUBE,L.H.

26

209-62-53450

TUBE,R.H.

27

07000-13035

O-RING (KIT)

28

01010-81060

BOLT

29

01643-51032

WASHER

30

07000-13038

O-RING (KIT)

31

01010-81245

BOLT

32

01643-31232

WASHER

33

707-88-21090

BAND

34

209-63-78160

BRACKET

35

209-63-78190

BRACKET

36

01010-81240

BOLT

37

01643-31232

WASHER

38

07282-03411

CLAMP

39

01010-81020

BOLT

40

01643-31032

WASHER

41

07283-23442

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

44

07000-13038

O-RING

45

07378-11210

HEAD

46

07371-51260

FLANGE

47

01010-81245

BOLT

48

01643-31232

WASHER

|$55

707-99-69660

SERVICE KIT
