Запчасти Komatsu PC750-6 ЦИЛИНДР РУКОЯТИ(ДЛЯ ПОГРУЗ.)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

209-63-X3331

CYLINDER GROUP

G-1

209-63-X3330

CYLINDER GROUP

|$3

209-63-03330

CYLINDER ASS'Y

1

209-63-66740

CYLINDER

2

707-46-14010

BUSHING

2A

21T-72-15860

BUSHING

2B

21T-72-15870

SEAL (KIT)

3

07043-00108

PLUG

4

707-27-22660

HEAD,CYLINDER

5

707-51-16030

PACKING,ROD (KIT)

6

707-51-16630

RING,BUFFER (KIT)

7

707-52-91350

BUSHING

8

566-63-22241

SEAL,DUST (KIT)

9

07179-14180

RING,SNAP

10

07000-15220

O-RING (KIT)

11

07001-05220

RING,BACK-UP (KIT)

12

01011-83010

BOLT

13

01643-33080

WASHER

14

209-63-66720

ROD,PISTON

15

707-46-14010

BUSHING

15A

21T-72-15860

BUSHING

15B

21T-72-15870

SEAL (KIT)

16

07043-00108

PLUG

17

707-36-22300

PISTON

18

07000-15135

O-RING (KIT)

19

707-35-91440

RING,BACK-UP (KIT)

20

707-44-22920

RING

21

707-39-22820

RING,WEAR (KIT)

22

707-44-22280

RING,PISTON (KIT)

23

707-40-22870

SPACER

24

707-71-60350

PLUNGER

25

04260-01270

BALL

26

707-71-91050

SCREW

27

01252-61670

BOLT

28

209-63-66770

TUBE

28

209-63-66771

TUBE

29

07000-13048

O-RING (KIT)

30

01010-81450

BOLT

31

01643-31445

WASHER

32

21N-62-18440

BAND

33

209-62-53250

BRACKET

34

209-62-53241

BRACKET

35

01010-81240

BOLT

36

01643-31232

WASHER

37

07282-14311

CLAMP

38

01010-81020

BOLT

39

01643-31032

WASHER

40

07283-34346

CLIP

41

01599-01011

NUT

42

01643-31032

WASHER

43

07000-13048

O-RING

44

07378-11410

HEAD

45

07371-51470

FLANGE

46

01010-41455

BOLT

47

01643-31445

WASHER

|$57

707-99-78690

SERVICE KIT
