Запчасти Komatsu PC750-6 ЦИЛИНДР РУКОЯТИ(ДЛЯ 8.M СТРЕЛА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY061

CYLINDER GROUP,(FINAL COATING)

G-1

707-01-XY060

CYLINDER GROUP,(FINAL COATING)

|$5

707-01-0A551

CYLINDER ASS'Y

|$6

707-01-0A550

CYLINDER ASS'Y

1

707-13-20250

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-27-20960

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14640

RING,BUFFER (KIT)

7

707-52-91170

BUSHING

8

198-63-93170

SEAL,DUST (KIT)

9

07179-14160

RING,SNAP

10

07000-15190

O-RING (KIT)

11

707-35-92020

RING,BACK-UP (KIT)

12

07000-15190

O-RING (KIT)

13

707-35-92020

RING,BACK-UP (KIT)

14

707-71-32980

COLLAR

15

01011-82705

BOLT

16

01643-32780

WASHER

17

209-63-64320

ROD,PISTON

18

707-46-11520

BUSHING

19

07043-00108

PLUG

20

707-36-20450

PISTON

21

07000-15130

O-RING (KIT)

22

07001-05130

RING,BACK-UP (KIT)

23

707-44-20910

RING

24

707-39-20820

RING,WEAR (KIT)

25

707-44-20180

RING,PISTON (KIT)

26

707-71-70330

PLUNGER

27

04260-00952

BALL

28

707-71-91230

CAP

29

707-71-61510

PLUNGER

29

707-71-61500

PLUNGER

30

01310-01232

SCREW

31

707-86-14040

TUBE

32

07000-13038

O-RING (KIT)

33

01010-81280

BOLT

34

01643-31232

WASHER

35

707-88-96110

BAND

36

707-88-96130

BAND

37

01010-81240

BOLT

38

01643-51232

WASHER

39

07283-34346

CLIP

40

01599-01011

NUT

41

01643-31032

WASHER

42

07000-13048

O-RING

43

07378-11410

HEAD

44

07371-51470

FLANGE

45

01010-81455

BOLT

46

01643-31445

WASHER

|$55

707-99-77160

SERVICE KIT
