Запчасти Komatsu PC750-6-AM ЦИЛИНДР РУКОЯТИ(ДЛЯ ПОГРУЗ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY891

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0C471

CYLINDER ASS'Y

1

209-63-66740

CYLINDER

2

707-46-14010

BUSHING

2A

21T-72-15860

BUSHING

2B

21T-72-15870

SEAL (KIT)

3

07043-00108

PLUG

4

707-27-22660

HEAD,CYLINDER

5

707-51-16030

PACKING,ROD (KIT)

6

707-51-16640

RING,BUFFER (KIT)

7

707-52-91350

BUSHING

8

566-63-22241

SEAL,DUST (KIT)

9

07179-14180

RING,SNAP

10

07000-15220

O-RING (KIT)

11

07001-05220

RING,BACK-UP (KIT)

12

01011-83010

BOLT

13

01643-33080

WASHER

14

209-63-66720

ROD,PISTON

15

707-46-14010

BUSHING

15A

21T-72-15860

BUSHING

15B

21T-72-15870

SEAL (KIT)

16

07043-00108

PLUG

17

707-36-22300

PISTON

18

07000-15135

O-RING (KIT)

19

707-35-91440

RING,BACK-UP (KIT)

20

707-44-22920

RING

21

707-39-22820

RING,WEAR (KIT)

22

707-44-22280

RING,PISTON (KIT)

23

707-40-22870

SPACER

24

707-71-60350

PLUNGER

25

04260-01270

BALL

26

707-71-91050

SCREW

27

01252-61670

BOLT

28

707-86-14051

TUBE

28A

707-86-14061

TUBE

29

07000-13048

O-RING (KIT)

30

01010-81450

BOLT

31

01643-31445

WASHER

32

21N-62-18440

BAND

33

707-88-25270

BRACKET

34

707-88-22771

BRACKET

35

01435-01235

BOLT

36

07282-14311

CLAMP

37

01435-01020

BOLT

38

176-61-41330

CLAMP

39

01435-01250

BOLT

40

07000-13048

O-RING

41

07378-11410

HEAD

42

07371-51470

FLANGE

43

01010-41455

BOLT

44

01643-31445

WASHER

|K

707-99-78730

SERVICE KIT
