Запчасти Komatsu PC750-6-AM ЦИЛИНДР СТРЕЛЫ(ДЛЯ ПОГРУЗ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY871

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XY881

CYLINDER GROUP,R.H. (FINAL COATING)

|1

707-01-0C451

CYLINDER ASS'Y

1

707-13-20311

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-27-20960

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14640

RING,BUFFER (KIT)

7

707-52-91170

BUSHING

8

198-63-93170

SEAL,DUST (KIT)

9

07179-14160

RING,SNAP

10

07000-15190

O-RING (KIT)

11

707-35-92020

RING,BACK-UP (KIT)

12

07000-15190

O-RING (KIT)

13

707-35-92020

RING,BACK-UP (KIT)

14

707-71-34830

COLLAR

15

01011-82705

BOLT

16

01643-32780

WASHER

17

707-58-14170

ROD,PISTON

18

707-46-11520

BUSHING

19

07043-00108

PLUG

20

707-36-20430

PISTON

21

07000-15130

O-RING (KIT)

22

07001-05130

RING,BACK-UP (KIT)

23

707-44-20910

RING

24

707-39-20820

RING,WEAR (KIT)

25

707-44-20180

RING,PISTON (KIT)

26

01310-01232

SCREW

27

707-71-61500

PLUNGER

28

707-86-11850

TUBE,L.H.

|28

707-86-11840

TUBE,R.H.

29

209-63-56880

TUBE,L.H.

|29

209-63-56870

TUBE,R.H.

30

07000-13038

O-RING (KIT)

31

01435-01240

BOLT

32

07378-11210

HEAD

33

07000-13038

O-RING

34

07371-51260

FLANGE

35

01010-81245

BOLT

36

01643-31232

WASHER

37

707-88-96110

BAND

38

707-88-25260

BRACKET

39

01435-01235

BOLT

40

07283-33442

CLIP

41

01597-01009

NUT

42

01643-31032

WASHER

|K

707-99-77300

SERVICE KIT
