Запчасти Komatsu PC75-1 ГИДРОЛИНИЯ (КЛАПАН PPCЛИНИЯ ПОДАЧИ) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

702-21-09192

VALVE, PPC PIPING

2

01253-41020

SCREW

3

21D-09-69620

O-RING

4

21D-09-54900

PRESSURE TAKE-UP

5

21D-09-59130

REDUCTION

6

22E-09-11220

UNION

7

21D-09-69960

O-RING

8

21D-09-97490

HOSE

9

21D-09-51640

ELBOW

10

21D-09-69970

O-RING

11

21D-60-11170

FILTER, ASSY.

12

21D-60-11220

CARTRIDGE

13

21D-60-11250

GASKET KIT

14

22E-62-12230

UNION

15

21D-09-69970

O-RING

16

21D-09-86220

GASKET

17

22E-62-12220

VALVE

18

21D-09-86280

GASKET

19

22E-62-12210

BLOCK

20

01010-50820

BOLT

21

01643-30823

WASHER

22

21D-60-17310

ACCUMULATOR

23

21D-09-73200

WASHER

24

21D-09-61560

UNION

25

21D-09-73190

GASKET

26

21D-09-54730

PLUG

27

21D-09-86280

GASKET

28

21D-09-51630

ELBOW

29

21D-09-69910

O-RING

30

21D-09-97430

HOSE

31

21D-09-51620

ELBOW

32

21D-09-69960

O-RING

33

21D-09-56530

UNION

34

21D-09-69910

O-RING

35

21D-09-51190

UNION

36

21D-09-69910

O-RING

37

21D-09-97430

HOSE

38

21D-09-51190

UNION

39

21D-09-69910

O-RING
