Запчасти Komatsu PC700LC-8R POWER TAKEOFF, PTO(МЕХ-М ОТБОРА МОЩНОСТИ) ASSEMBLY (№7-) POWER TAKEOFF

Схема запчастей Komatsu PC700LC-8R - POWER TAKEOFF, PTO(МЕХ-М ОТБОРА МОЩНОСТИ) ASSEMBLY (№7-) POWER TAKEOFF
23
1
3
2
4
6
5
17
16
20
18
19
22
21
22
22
21
22
24
9
11
14
7
12
13
8
10
15
25
26
26

Артикул

Название

Примечание

Количество

|$0

21M-38-00110

Power take off Assembly

1

21M-38-21510

Case

2

21M-38-21121

Case

3

21M-38-11140

Gasket

4

01010-81240

Bolt

5

01643-31232

Washer

6

04020-01434

Pin, Dowel

6

6693-22-5600

Valve Assembly

7

Body

8

6693-22-5620

Valve

9

07040-02412

Plug

10

04020-00514

Pin, Dowel

11

07000-E3028

O-ring

12

01010-81030

Bolt

13

01643-31032

Washer

14

07030-03034

Breather

15

07005-03016

Seal, Washer

16

21M-38-21340

Gear

17

06030-06224

Bearing

18

21M-38-11570

Bearing

19

04064-09530

Ring, Snap

20

04071-00170

Ring, Snap

21

21M-38-11350

Gear

22

06030-06219

Bearing

23

07030-10252

Breather

24

21M-38-11410

Seal

25

209-38-11270

Nipple

26

07049-02430

Plug

Выбрано товаров: 28
